I did everything according to the scheme, and I ran into such a problem that esphome does not see the connected e16t device via usb. I used the cable from the e16t kit, I also tried to use another cable, but with no result.

After that I tried to connect e16t to PC (windows), but PC cannot detect e16t. The driver for the ch340c is installed.
Nothing happens when connected to a PC.

Can you tell me how to solve this problem?]]> I found a post on the forum that you can install a new configuration file on the e16t (via esphome), which will allow you to control the relay via tuya and home assistant.
I did everything according to the scheme, and I ran into such a problem that esphome does not see the connected e16t device via usb. I used the cable from the e16t kit, I also tried to use another cable, but with no result.

After that I tried to connect e16t to PC (windows), but PC cannot detect e16t. The driver for the ch340c is installed.
Nothing happens when connected to a PC.

Can you tell me how to solve this problem?]]> <![CDATA[KC868-E16T added Tuya module and input toggle output yaml file for ESPHome]]> https://www.kincony.com/forum/showthread.php?tid=7827 Tue, 18 Mar 2025 18:05:58 +0800 admin]]> https://www.kincony.com/forum/showthread.php?tid=7827

Code:

esphome:

  name: e16t

  platformio_options:

    board_build.extra_flags:

      # WIFI_CONTROL_SELF_MODE = 0

      # WIFI_CONTROL_SELF_MODE = 1

      - "-DWIFI_CONTROL_SELF_MODE=0"



esp32:

  board: esp32dev

  framework:

    type: arduino



external_components:

  - source:

      type: git

      url: https://github.com/hzkincony/esphome-tuya-wifi-mcu

      ref: v1.1.0



uart:

  tx_pin: 33

  rx_pin: 14

  id: tuya_mcu_uart

  baud_rate: 9600



tuya_wifi_mcu:

  # tuya mcu product id

  product_id: tfj1dtlneyxp5uya

  uart_id: tuya_mcu_uart

  wifi_reset_pin: 5

  wifi_led_pin: 12





# Example configuration entry for ESP32

i2c:

  sda: 16

  scl: 15

  scan: true

  id: bus_a





# Example configuration entry

ethernet:

  type: LAN8720

  mdc_pin: GPIO23

  mdio_pin: GPIO18

  clk_mode: GPIO17_OUT

  phy_addr: 0



# Example configuration entry

pcf8574:

  - id: 'pcf8574_hub_out_1'  # for output channel 1-8

    address: 0x21



  - id: 'pcf8574_hub_out_2'  # for output channel 9-16

    address: 0x25



  - id: 'pcf8574_hub_in_1'  # for input channel 1-8

    address: 0x22



  - id: 'pcf8574_hub_in_2'  # for input channel 9-16

    address: 0x24



# Individual outputs

switch:

  - platform: gpio

    name: "e16t_output1"

    id: "e16t_output1"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 0

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output1-tuya

    dp_id: 1

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output1"





  - platform: gpio

    name: "e16t_output2"

    id: "e16t_output2"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 1

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output2-tuya

    dp_id: 2

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output2"



  - platform: gpio

    name: "e16t_output3"

    id: "e16t_output3"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 2

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output3-tuya

    dp_id: 3

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output3"



  - platform: gpio

    name: "e16t_output4"

    id: "e16t_output4"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 3

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output4-tuya

    dp_id: 4

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output4"



  - platform: gpio

    name: "e16t_output5"

    id: "e16t_output5"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 4

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output5-tuya

    dp_id: 5

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output5"



  - platform: gpio

    name: "e16t_output6"

    id: "e16t_output6"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 5

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output6-tuya

    dp_id: 6

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output6"



  - platform: gpio

    name: "e16t_output7"

    id: "e16t_output7"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 6

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output7-tuya

    dp_id: 101

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output7"



  - platform: gpio

    name: "e16t_output8"

    id: "e16t_output8"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 7

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output8-tuya

    dp_id: 102

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output8"



  - platform: gpio

    name: "e16t_output9"

    id: "e16t_output9"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 0

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output9-tuya

    dp_id: 103

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output9"



  - platform: gpio

    name: "e16t_output10"

    id: "e16t_output10"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 1

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output10-tuya

    dp_id: 104

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output10"



  - platform: gpio

    name: "e16t_output11"

    id: "e16t_output11"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 2

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output11-tuya

    dp_id: 105

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output11"



  - platform: gpio

    name: "e16t_output12"

    id: "e16t_output12"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 3

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output12-tuya

    dp_id: 106

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output12"



  - platform: gpio

    name: "e16t_output13"

    id: "e16t_output13"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 4

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output13-tuya

    dp_id: 107

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output13"



  - platform: gpio

    name: "e16t_output14"

    id: "e16t_output14"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 5

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output14-tuya

    dp_id: 108

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output14"



  - platform: gpio

    name: "e16t_output15"

    id: "e16t_output15"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 6

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output15-tuya

    dp_id: 109

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output15"



  - platform: gpio

    name: "e16t_output16"

    id: "e16t_output16"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 7

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output16-tuya

    dp_id: 110

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output16"



binary_sensor:

  - platform: gpio

    name: "e16t-input1"

    id: "e16t_input1"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 0

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output1

  - platform: tuya_wifi_mcu

    name: e16t DI01 Tuya

    dp_id: 111

    bind_binary_sensor_id: e16t_input1

    internal: true



  - platform: gpio

    name: "e16t-input2"

    id: "e16t_input2"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 1

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output2

  - platform: tuya_wifi_mcu

    name: e16t DI02 Tuya

    dp_id: 112

    bind_binary_sensor_id: e16t_input2

    internal: true



  - platform: gpio

    name: "e16t-input3"

    id: "e16t_input3"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 2

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output3

  - platform: tuya_wifi_mcu

    name: e16t DI03 Tuya

    dp_id: 113

    bind_binary_sensor_id: e16t_input3

    internal: true



  - platform: gpio

    name: "e16t-input4"

    id: "e16t_input4"

    on_press:

      then:

        - switch.toggle: e16t_output4

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 3

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI04 Tuya

    dp_id: 114

    bind_binary_sensor_id: e16t_input4

    internal: true



  - platform: gpio

    name: "e16t-input5"

    id: "e16t_input5"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 4

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output5

  - platform: tuya_wifi_mcu

    name: e16t DI05 Tuya

    dp_id: 115

    bind_binary_sensor_id: e16t_input5

    internal: true



  - platform: gpio

    name: "e16t-input6"

    id: "e16t_input6"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 5

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output6

  - platform: tuya_wifi_mcu

    name: e16t DI06 Tuya

    dp_id: 116

    bind_binary_sensor_id: e16t_input6

    internal: true



  - platform: gpio

    name: "e16t-input7"

    id: "e16t_input7"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 6

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output7

  - platform: tuya_wifi_mcu

    name: e16t DI07 Tuya

    dp_id: 117

    bind_binary_sensor_id: e16t_input7

    internal: true



  - platform: gpio

    name: "e16t-input8"

    id: "e16t_input8"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 7

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output8

  - platform: tuya_wifi_mcu

    name: e16t DI08 Tuya

    dp_id: 118

    bind_binary_sensor_id: e16t_input8

    internal: true



  - platform: gpio

    name: "e16t-input9"

    id: "e16t_input9"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 0

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output9

  - platform: tuya_wifi_mcu

    name: e16t DI09 Tuya

    dp_id: 119

    bind_binary_sensor_id: e16t_input9

    internal: true



  - platform: gpio

    name: "e16t-input10"

    id: "e16t_input10"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 1

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output10

  - platform: tuya_wifi_mcu

    name: e16t DI10 Tuya

    dp_id: 120

    bind_binary_sensor_id: e16t_input10

    internal: true



  - platform: gpio

    name: "e16t-input11"

    id: "e16t_input11"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 2

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output11

  - platform: tuya_wifi_mcu

    name: e16t DI11 Tuya

    dp_id: 121

    bind_binary_sensor_id: e16t_input11

    internal: true



  - platform: gpio

    name: "e16t-input12"

    id: "e16t_input12"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 3

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output12

  - platform: tuya_wifi_mcu

    name: e16t DI12 Tuya

    dp_id: 122

    bind_binary_sensor_id: e16t_input12

    internal: true



  - platform: gpio

    name: "e16t-input13"

    id: "e16t_input13"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 4

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output13

  - platform: tuya_wifi_mcu

    name: e16t DI13 Tuya

    dp_id: 123

    bind_binary_sensor_id: e16t_input13

    internal: true



  - platform: gpio

    name: "e16t-input14"

    id: "e16t_input14"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 5

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output14

  - platform: tuya_wifi_mcu

    name: e16t DI14 Tuya

    dp_id: 124

    bind_binary_sensor_id: e16t_input14

    internal: true



  - platform: gpio

    name: "e16t-input15"

    id: "e16t_input15"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 6

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output15

  - platform: tuya_wifi_mcu

    name: e16t DI15 Tuya

    dp_id: 125

    bind_binary_sensor_id: e16t_input15

    internal: true



  - platform: gpio

    name: "e16t-input16"

    id: "e16t_input16"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 7

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output16

  - platform: tuya_wifi_mcu

    name: e16t DI16 Tuya

    dp_id: 126

    bind_binary_sensor_id: e16t_input16

    internal: true



# Enable logging

logger:



# Enable Home Assistant API

api:

firmware BIN file download:

.zip

e16t.factory_tuya.zip (Size: 372.83 KB / Downloads: 644) ]]>

Code:

esphome:

  name: e16t

  platformio_options:

    board_build.extra_flags:

      # WIFI_CONTROL_SELF_MODE = 0

      # WIFI_CONTROL_SELF_MODE = 1

      - "-DWIFI_CONTROL_SELF_MODE=0"



esp32:

  board: esp32dev

  framework:

    type: arduino



external_components:

  - source:

      type: git

      url: https://github.com/hzkincony/esphome-tuya-wifi-mcu

      ref: v1.1.0



uart:

  tx_pin: 33

  rx_pin: 14

  id: tuya_mcu_uart

  baud_rate: 9600



tuya_wifi_mcu:

  # tuya mcu product id

  product_id: tfj1dtlneyxp5uya

  uart_id: tuya_mcu_uart

  wifi_reset_pin: 5

  wifi_led_pin: 12





# Example configuration entry for ESP32

i2c:

  sda: 16

  scl: 15

  scan: true

  id: bus_a





# Example configuration entry

ethernet:

  type: LAN8720

  mdc_pin: GPIO23

  mdio_pin: GPIO18

  clk_mode: GPIO17_OUT

  phy_addr: 0



# Example configuration entry

pcf8574:

  - id: 'pcf8574_hub_out_1'  # for output channel 1-8

    address: 0x21



  - id: 'pcf8574_hub_out_2'  # for output channel 9-16

    address: 0x25



  - id: 'pcf8574_hub_in_1'  # for input channel 1-8

    address: 0x22



  - id: 'pcf8574_hub_in_2'  # for input channel 9-16

    address: 0x24



# Individual outputs

switch:

  - platform: gpio

    name: "e16t_output1"

    id: "e16t_output1"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 0

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output1-tuya

    dp_id: 1

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output1"





  - platform: gpio

    name: "e16t_output2"

    id: "e16t_output2"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 1

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output2-tuya

    dp_id: 2

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output2"



  - platform: gpio

    name: "e16t_output3"

    id: "e16t_output3"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 2

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output3-tuya

    dp_id: 3

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output3"



  - platform: gpio

    name: "e16t_output4"

    id: "e16t_output4"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 3

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output4-tuya

    dp_id: 4

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output4"



  - platform: gpio

    name: "e16t_output5"

    id: "e16t_output5"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 4

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output5-tuya

    dp_id: 5

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output5"



  - platform: gpio

    name: "e16t_output6"

    id: "e16t_output6"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 5

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output6-tuya

    dp_id: 6

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output6"



  - platform: gpio

    name: "e16t_output7"

    id: "e16t_output7"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 6

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output7-tuya

    dp_id: 101

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output7"



  - platform: gpio

    name: "e16t_output8"

    id: "e16t_output8"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 7

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output8-tuya

    dp_id: 102

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output8"



  - platform: gpio

    name: "e16t_output9"

    id: "e16t_output9"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 0

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output9-tuya

    dp_id: 103

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output9"



  - platform: gpio

    name: "e16t_output10"

    id: "e16t_output10"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 1

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output10-tuya

    dp_id: 104

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output10"



  - platform: gpio

    name: "e16t_output11"

    id: "e16t_output11"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 2

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output11-tuya

    dp_id: 105

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output11"



  - platform: gpio

    name: "e16t_output12"

    id: "e16t_output12"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 3

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output12-tuya

    dp_id: 106

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output12"



  - platform: gpio

    name: "e16t_output13"

    id: "e16t_output13"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 4

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output13-tuya

    dp_id: 107

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output13"



  - platform: gpio

    name: "e16t_output14"

    id: "e16t_output14"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 5

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output14-tuya

    dp_id: 108

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output14"



  - platform: gpio

    name: "e16t_output15"

    id: "e16t_output15"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 6

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output15-tuya

    dp_id: 109

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output15"



  - platform: gpio

    name: "e16t_output16"

    id: "e16t_output16"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 7

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output16-tuya

    dp_id: 110

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output16"



binary_sensor:

  - platform: gpio

    name: "e16t-input1"

    id: "e16t_input1"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 0

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output1

  - platform: tuya_wifi_mcu

    name: e16t DI01 Tuya

    dp_id: 111

    bind_binary_sensor_id: e16t_input1

    internal: true



  - platform: gpio

    name: "e16t-input2"

    id: "e16t_input2"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 1

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output2

  - platform: tuya_wifi_mcu

    name: e16t DI02 Tuya

    dp_id: 112

    bind_binary_sensor_id: e16t_input2

    internal: true



  - platform: gpio

    name: "e16t-input3"

    id: "e16t_input3"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 2

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output3

  - platform: tuya_wifi_mcu

    name: e16t DI03 Tuya

    dp_id: 113

    bind_binary_sensor_id: e16t_input3

    internal: true



  - platform: gpio

    name: "e16t-input4"

    id: "e16t_input4"

    on_press:

      then:

        - switch.toggle: e16t_output4

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 3

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI04 Tuya

    dp_id: 114

    bind_binary_sensor_id: e16t_input4

    internal: true



  - platform: gpio

    name: "e16t-input5"

    id: "e16t_input5"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 4

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output5

  - platform: tuya_wifi_mcu

    name: e16t DI05 Tuya

    dp_id: 115

    bind_binary_sensor_id: e16t_input5

    internal: true



  - platform: gpio

    name: "e16t-input6"

    id: "e16t_input6"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 5

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output6

  - platform: tuya_wifi_mcu

    name: e16t DI06 Tuya

    dp_id: 116

    bind_binary_sensor_id: e16t_input6

    internal: true



  - platform: gpio

    name: "e16t-input7"

    id: "e16t_input7"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 6

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output7

  - platform: tuya_wifi_mcu

    name: e16t DI07 Tuya

    dp_id: 117

    bind_binary_sensor_id: e16t_input7

    internal: true



  - platform: gpio

    name: "e16t-input8"

    id: "e16t_input8"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 7

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output8

  - platform: tuya_wifi_mcu

    name: e16t DI08 Tuya

    dp_id: 118

    bind_binary_sensor_id: e16t_input8

    internal: true



  - platform: gpio

    name: "e16t-input9"

    id: "e16t_input9"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 0

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output9

  - platform: tuya_wifi_mcu

    name: e16t DI09 Tuya

    dp_id: 119

    bind_binary_sensor_id: e16t_input9

    internal: true



  - platform: gpio

    name: "e16t-input10"

    id: "e16t_input10"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 1

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output10

  - platform: tuya_wifi_mcu

    name: e16t DI10 Tuya

    dp_id: 120

    bind_binary_sensor_id: e16t_input10

    internal: true



  - platform: gpio

    name: "e16t-input11"

    id: "e16t_input11"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 2

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output11

  - platform: tuya_wifi_mcu

    name: e16t DI11 Tuya

    dp_id: 121

    bind_binary_sensor_id: e16t_input11

    internal: true



  - platform: gpio

    name: "e16t-input12"

    id: "e16t_input12"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 3

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output12

  - platform: tuya_wifi_mcu

    name: e16t DI12 Tuya

    dp_id: 122

    bind_binary_sensor_id: e16t_input12

    internal: true



  - platform: gpio

    name: "e16t-input13"

    id: "e16t_input13"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 4

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output13

  - platform: tuya_wifi_mcu

    name: e16t DI13 Tuya

    dp_id: 123

    bind_binary_sensor_id: e16t_input13

    internal: true



  - platform: gpio

    name: "e16t-input14"

    id: "e16t_input14"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 5

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output14

  - platform: tuya_wifi_mcu

    name: e16t DI14 Tuya

    dp_id: 124

    bind_binary_sensor_id: e16t_input14

    internal: true



  - platform: gpio

    name: "e16t-input15"

    id: "e16t_input15"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 6

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output15

  - platform: tuya_wifi_mcu

    name: e16t DI15 Tuya

    dp_id: 125

    bind_binary_sensor_id: e16t_input15

    internal: true



  - platform: gpio

    name: "e16t-input16"

    id: "e16t_input16"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 7

      mode: INPUT

      inverted: true

    on_press:

      then:

        - switch.toggle: e16t_output16

  - platform: tuya_wifi_mcu

    name: e16t DI16 Tuya

    dp_id: 126

    bind_binary_sensor_id: e16t_input16

    internal: true



# Enable logging

logger:



# Enable Home Assistant API

api:

firmware BIN file download:

.zip

e16t.factory_tuya.zip (Size: 372.83 KB / Downloads: 644) ]]> <![CDATA[Factory reset]]> https://www.kincony.com/forum/showthread.php?tid=6019 Thu, 04 Jul 2024 14:25:01 +0800 Chestie]]> https://www.kincony.com/forum/showthread.php?tid=6019
is there any way to factory reset the board?

I deactivated the wifi inside and my router is not able to assign an IP somehow when connected by ETH so I cannot interact with it.

Any ideas? Smile

]]>
is there any way to factory reset the board?

I deactivated the wifi inside and my router is not able to assign an IP somehow when connected by ETH so I cannot interact with it.

Any ideas? Smile

]]> <![CDATA[KC868-E16T added Tuya module yaml file for ESPHome]]> https://www.kincony.com/forum/showthread.php?tid=5847 Wed, 05 Jun 2024 10:16:56 +0800 admin]]> https://www.kincony.com/forum/showthread.php?tid=5847

Code:

esphome:

  name: e16t

  platform: ESP32

  board: esp32dev

  platformio_options:

    board_build.extra_flags:

      # WIFI_CONTROL_SELF_MODE = 0

      # WIFI_CONTROL_SELF_MODE = 1

      - "-DWIFI_CONTROL_SELF_MODE=0"





external_components:

  - source:

      type: git

      url: https://github.com/hzkincony/esphome-tuya-wifi-mcu

      ref: v1.1.0



uart:

  tx_pin: 33

  rx_pin: 14

  id: tuya_mcu_uart

  baud_rate: 9600



tuya_wifi_mcu:

  # tuya mcu product id

  product_id: tfj1dtlneyxp5uya

  uart_id: tuya_mcu_uart

  wifi_reset_pin: 5

  wifi_led_pin: 12





# Example configuration entry for ESP32

i2c:

  sda: 16

  scl: 15

  scan: true

  id: bus_a





# Example configuration entry

ethernet:

  type: LAN8720

  mdc_pin: GPIO23

  mdio_pin: GPIO18

  clk_mode: GPIO17_OUT

  phy_addr: 0



# Example configuration entry

pcf8574:

  - id: 'pcf8574_hub_out_1'  # for output channel 1-8

    address: 0x21



  - id: 'pcf8574_hub_out_2'  # for output channel 9-16

    address: 0x25



  - id: 'pcf8574_hub_in_1'  # for input channel 1-8

    address: 0x22



  - id: 'pcf8574_hub_in_2'  # for input channel 9-16

    address: 0x24



# Individual outputs

switch:

  - platform: gpio

    name: "e16t_output1"

    id: "e16t_output1"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 0

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output1-tuya

    dp_id: 1

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output1"





  - platform: gpio

    name: "e16t_output2"

    id: "e16t_output2"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 1

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output2-tuya

    dp_id: 2

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output2"



  - platform: gpio

    name: "e16t_output3"

    id: "e16t_output3"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 2

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output3-tuya

    dp_id: 3

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output3"



  - platform: gpio

    name: "e16t_output4"

    id: "e16t_output4"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 3

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output4-tuya

    dp_id: 4

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output4"



  - platform: gpio

    name: "e16t_output5"

    id: "e16t_output5"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 4

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output5-tuya

    dp_id: 5

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output5"



  - platform: gpio

    name: "e16t_output6"

    id: "e16t_output6"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 5

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output6-tuya

    dp_id: 6

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output6"



  - platform: gpio

    name: "e16t_output7"

    id: "e16t_output7"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 6

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output7-tuya

    dp_id: 101

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output7"



  - platform: gpio

    name: "e16t_output8"

    id: "e16t_output8"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 7

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output8-tuya

    dp_id: 102

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output8"



  - platform: gpio

    name: "e16t_output9"

    id: "e16t_output9"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 0

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output9-tuya

    dp_id: 103

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output9"



  - platform: gpio

    name: "e16t_output10"

    id: "e16t_output10"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 1

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output10-tuya

    dp_id: 104

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output10"



  - platform: gpio

    name: "e16t_output11"

    id: "e16t_output11"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 2

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output11-tuya

    dp_id: 105

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output11"



  - platform: gpio

    name: "e16t_output12"

    id: "e16t_output12"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 3

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output12-tuya

    dp_id: 106

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output12"



  - platform: gpio

    name: "e16t_output13"

    id: "e16t_output13"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 4

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output13-tuya

    dp_id: 107

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output13"



  - platform: gpio

    name: "e16t_output14"

    id: "e16t_output14"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 5

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output14-tuya

    dp_id: 108

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output14"



  - platform: gpio

    name: "e16t_output15"

    id: "e16t_output15"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 6

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output15-tuya

    dp_id: 109

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output15"



  - platform: gpio

    name: "e16t_output16"

    id: "e16t_output16"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 7

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output16-tuya

    dp_id: 110

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output16"



binary_sensor:

  - platform: gpio

    name: "e16t-input1"

    id: "e16t_input1"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 0

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI01 Tuya

    dp_id: 111

    bind_binary_sensor_id: e16t_input1

    internal: true



  - platform: gpio

    name: "e16t-input2"

    id: "e16t_input2"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 1

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI02 Tuya

    dp_id: 112

    bind_binary_sensor_id: e16t_input2

    internal: true



  - platform: gpio

    name: "e16t-input3"

    id: "e16t_input3"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 2

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI03 Tuya

    dp_id: 113

    bind_binary_sensor_id: e16t_input3

    internal: true



  - platform: gpio

    name: "e16t-input4"

    id: "e16t_input4"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 3

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI04 Tuya

    dp_id: 114

    bind_binary_sensor_id: e16t_input4

    internal: true



  - platform: gpio

    name: "e16t-input5"

    id: "e16t_input5"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 4

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI05 Tuya

    dp_id: 115

    bind_binary_sensor_id: e16t_input5

    internal: true



  - platform: gpio

    name: "e16t-input6"

    id: "e16t_input6"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 5

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI06 Tuya

    dp_id: 116

    bind_binary_sensor_id: e16t_input6

    internal: true



  - platform: gpio

    name: "e16t-input7"

    id: "e16t_input7"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 6

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI07 Tuya

    dp_id: 117

    bind_binary_sensor_id: e16t_input7

    internal: true



  - platform: gpio

    name: "e16t-input8"

    id: "e16t_input8"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 7

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI08 Tuya

    dp_id: 118

    bind_binary_sensor_id: e16t_input8

    internal: true



  - platform: gpio

    name: "e16t-input9"

    id: "e16t_input9"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 0

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI09 Tuya

    dp_id: 119

    bind_binary_sensor_id: e16t_input9

    internal: true



  - platform: gpio

    name: "e16t-input10"

    id: "e16t_input10"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 1

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI10 Tuya

    dp_id: 120

    bind_binary_sensor_id: e16t_input10

    internal: true



  - platform: gpio

    name: "e16t-input11"

    id: "e16t_input11"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 2

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI11 Tuya

    dp_id: 121

    bind_binary_sensor_id: e16t_input11

    internal: true



  - platform: gpio

    name: "e16t-input12"

    id: "e16t_input12"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 3

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI12 Tuya

    dp_id: 122

    bind_binary_sensor_id: e16t_input12

    internal: true



  - platform: gpio

    name: "e16t-input13"

    id: "e16t_input13"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 4

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI13 Tuya

    dp_id: 123

    bind_binary_sensor_id: e16t_input13

    internal: true



  - platform: gpio

    name: "e16t-input14"

    id: "e16t_input14"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 5

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI14 Tuya

    dp_id: 124

    bind_binary_sensor_id: e16t_input14

    internal: true



  - platform: gpio

    name: "e16t-input15"

    id: "e16t_input15"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 6

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI15 Tuya

    dp_id: 125

    bind_binary_sensor_id: e16t_input15

    internal: true



  - platform: gpio

    name: "e16t-input16"

    id: "e16t_input16"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 7

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI16 Tuya

    dp_id: 126

    bind_binary_sensor_id: e16t_input16

    internal: true



# Enable logging

logger:



# Enable Home Assistant API

api:

download yaml file:
.txt

E16T-HA-Tuya.txt (Size: 11.91 KB / Downloads: 604)

]]>

Code:

esphome:

  name: e16t

  platform: ESP32

  board: esp32dev

  platformio_options:

    board_build.extra_flags:

      # WIFI_CONTROL_SELF_MODE = 0

      # WIFI_CONTROL_SELF_MODE = 1

      - "-DWIFI_CONTROL_SELF_MODE=0"





external_components:

  - source:

      type: git

      url: https://github.com/hzkincony/esphome-tuya-wifi-mcu

      ref: v1.1.0



uart:

  tx_pin: 33

  rx_pin: 14

  id: tuya_mcu_uart

  baud_rate: 9600



tuya_wifi_mcu:

  # tuya mcu product id

  product_id: tfj1dtlneyxp5uya

  uart_id: tuya_mcu_uart

  wifi_reset_pin: 5

  wifi_led_pin: 12





# Example configuration entry for ESP32

i2c:

  sda: 16

  scl: 15

  scan: true

  id: bus_a





# Example configuration entry

ethernet:

  type: LAN8720

  mdc_pin: GPIO23

  mdio_pin: GPIO18

  clk_mode: GPIO17_OUT

  phy_addr: 0



# Example configuration entry

pcf8574:

  - id: 'pcf8574_hub_out_1'  # for output channel 1-8

    address: 0x21



  - id: 'pcf8574_hub_out_2'  # for output channel 9-16

    address: 0x25



  - id: 'pcf8574_hub_in_1'  # for input channel 1-8

    address: 0x22



  - id: 'pcf8574_hub_in_2'  # for input channel 9-16

    address: 0x24



# Individual outputs

switch:

  - platform: gpio

    name: "e16t_output1"

    id: "e16t_output1"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 0

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output1-tuya

    dp_id: 1

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output1"





  - platform: gpio

    name: "e16t_output2"

    id: "e16t_output2"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 1

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output2-tuya

    dp_id: 2

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output2"



  - platform: gpio

    name: "e16t_output3"

    id: "e16t_output3"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 2

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output3-tuya

    dp_id: 3

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output3"



  - platform: gpio

    name: "e16t_output4"

    id: "e16t_output4"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 3

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output4-tuya

    dp_id: 4

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output4"



  - platform: gpio

    name: "e16t_output5"

    id: "e16t_output5"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 4

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output5-tuya

    dp_id: 5

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output5"



  - platform: gpio

    name: "e16t_output6"

    id: "e16t_output6"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 5

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output6-tuya

    dp_id: 6

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output6"



  - platform: gpio

    name: "e16t_output7"

    id: "e16t_output7"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 6

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output7-tuya

    dp_id: 101

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output7"



  - platform: gpio

    name: "e16t_output8"

    id: "e16t_output8"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 7

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output8-tuya

    dp_id: 102

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output8"



  - platform: gpio

    name: "e16t_output9"

    id: "e16t_output9"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 0

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output9-tuya

    dp_id: 103

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output9"



  - platform: gpio

    name: "e16t_output10"

    id: "e16t_output10"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 1

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output10-tuya

    dp_id: 104

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output10"



  - platform: gpio

    name: "e16t_output11"

    id: "e16t_output11"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 2

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output11-tuya

    dp_id: 105

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output11"



  - platform: gpio

    name: "e16t_output12"

    id: "e16t_output12"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 3

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output12-tuya

    dp_id: 106

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output12"



  - platform: gpio

    name: "e16t_output13"

    id: "e16t_output13"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 4

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output13-tuya

    dp_id: 107

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output13"



  - platform: gpio

    name: "e16t_output14"

    id: "e16t_output14"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 5

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output14-tuya

    dp_id: 108

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output14"



  - platform: gpio

    name: "e16t_output15"

    id: "e16t_output15"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 6

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output15-tuya

    dp_id: 109

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output15"



  - platform: gpio

    name: "e16t_output16"

    id: "e16t_output16"

    pin:

      pcf8574: pcf8574_hub_out_2

      number: 7

      mode: OUTPUT

      inverted: true



  - platform: tuya_wifi_mcu

    name: e16t-output16-tuya

    dp_id: 110

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "e16t_output16"



binary_sensor:

  - platform: gpio

    name: "e16t-input1"

    id: "e16t_input1"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 0

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI01 Tuya

    dp_id: 111

    bind_binary_sensor_id: e16t_input1

    internal: true



  - platform: gpio

    name: "e16t-input2"

    id: "e16t_input2"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 1

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI02 Tuya

    dp_id: 112

    bind_binary_sensor_id: e16t_input2

    internal: true



  - platform: gpio

    name: "e16t-input3"

    id: "e16t_input3"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 2

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI03 Tuya

    dp_id: 113

    bind_binary_sensor_id: e16t_input3

    internal: true



  - platform: gpio

    name: "e16t-input4"

    id: "e16t_input4"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 3

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI04 Tuya

    dp_id: 114

    bind_binary_sensor_id: e16t_input4

    internal: true



  - platform: gpio

    name: "e16t-input5"

    id: "e16t_input5"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 4

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI05 Tuya

    dp_id: 115

    bind_binary_sensor_id: e16t_input5

    internal: true



  - platform: gpio

    name: "e16t-input6"

    id: "e16t_input6"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 5

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI06 Tuya

    dp_id: 116

    bind_binary_sensor_id: e16t_input6

    internal: true



  - platform: gpio

    name: "e16t-input7"

    id: "e16t_input7"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 6

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI07 Tuya

    dp_id: 117

    bind_binary_sensor_id: e16t_input7

    internal: true



  - platform: gpio

    name: "e16t-input8"

    id: "e16t_input8"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 7

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI08 Tuya

    dp_id: 118

    bind_binary_sensor_id: e16t_input8

    internal: true



  - platform: gpio

    name: "e16t-input9"

    id: "e16t_input9"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 0

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI09 Tuya

    dp_id: 119

    bind_binary_sensor_id: e16t_input9

    internal: true



  - platform: gpio

    name: "e16t-input10"

    id: "e16t_input10"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 1

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI10 Tuya

    dp_id: 120

    bind_binary_sensor_id: e16t_input10

    internal: true



  - platform: gpio

    name: "e16t-input11"

    id: "e16t_input11"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 2

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI11 Tuya

    dp_id: 121

    bind_binary_sensor_id: e16t_input11

    internal: true



  - platform: gpio

    name: "e16t-input12"

    id: "e16t_input12"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 3

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI12 Tuya

    dp_id: 122

    bind_binary_sensor_id: e16t_input12

    internal: true



  - platform: gpio

    name: "e16t-input13"

    id: "e16t_input13"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 4

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI13 Tuya

    dp_id: 123

    bind_binary_sensor_id: e16t_input13

    internal: true



  - platform: gpio

    name: "e16t-input14"

    id: "e16t_input14"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 5

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI14 Tuya

    dp_id: 124

    bind_binary_sensor_id: e16t_input14

    internal: true



  - platform: gpio

    name: "e16t-input15"

    id: "e16t_input15"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 6

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI15 Tuya

    dp_id: 125

    bind_binary_sensor_id: e16t_input15

    internal: true



  - platform: gpio

    name: "e16t-input16"

    id: "e16t_input16"

    pin:

      pcf8574: pcf8574_hub_in_2

      number: 7

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: e16t DI16 Tuya

    dp_id: 126

    bind_binary_sensor_id: e16t_input16

    internal: true



# Enable logging

logger:



# Enable Home Assistant API

api:

download yaml file:
.txt

E16T-HA-Tuya.txt (Size: 11.91 KB / Downloads: 604)

]]> <![CDATA[Tuya IoT platform parameter for KC868-E16T controller]]> https://www.kincony.com/forum/showthread.php?tid=5823 Fri, 31 May 2024 12:50:03 +0800 admin]]> https://www.kincony.com/forum/showthread.php?tid=5823
switch01 DP ID:1
switch02 DP ID:2
switch03 DP ID:3
switch04 DP ID:4
switch05 DP ID:5
switch06 DP ID:6
switch07 DP ID:101
switch08 DP ID:102
switch09 DP ID:103
switch10 DP ID:104
switch11 DP ID:105
switch12 DP ID:106
switch13 DP ID:107
switch14 DP ID:108
switch15 DP ID:109
switch16 DP ID:110

input01 DP ID:111
input02 DP ID:112
input03 DP ID:113
input04 DP ID:114
input05 DP ID:115
input06 DP ID:116
input07 DP ID:117
input08 DP ID:118
input09 DP ID:119
input10 DP ID:120
input11 DP ID:121
input12 DP ID:122
input13 DP ID:123
input14 DP ID:124
input15 DP ID:125
input16 DP ID:126]]>
switch01 DP ID:1
switch02 DP ID:2
switch03 DP ID:3
switch04 DP ID:4
switch05 DP ID:5
switch06 DP ID:6
switch07 DP ID:101
switch08 DP ID:102
switch09 DP ID:103
switch10 DP ID:104
switch11 DP ID:105
switch12 DP ID:106
switch13 DP ID:107
switch14 DP ID:108
switch15 DP ID:109
switch16 DP ID:110

input01 DP ID:111
input02 DP ID:112
input03 DP ID:113
input04 DP ID:114
input05 DP ID:115
input06 DP ID:116
input07 DP ID:117
input08 DP ID:118
input09 DP ID:119
input10 DP ID:120
input11 DP ID:121
input12 DP ID:122
input13 DP ID:123
input14 DP ID:124
input15 DP ID:125
input16 DP ID:126]]> <![CDATA[Questions and requests]]> https://www.kincony.com/forum/showthread.php?tid=4347 Fri, 16 Feb 2024 21:30:53 +0800 tech1977]]> https://www.kincony.com/forum/showthread.php?tid=4347 I received the board, It seems like a great relay board to me Wink

-can the ETH WEB Server work together with tuya?
-can analog inputs work with Tuya?
-How can I use an contact input with a physical button to turn all the others off and on all the relays together?
-why with Alexa if I say turn off or turn on all E16T does it turn on and off only the first 4 relays?
-why are the 16 channels not dry contact but 24v?

Thanks for support]]> I received the board, It seems like a great relay board to me Wink

-can the ETH WEB Server work together with tuya?
-can analog inputs work with Tuya?
-How can I use an contact input with a physical button to turn all the others off and on all the relays together?
-why with Alexa if I say turn off or turn on all E16T does it turn on and off only the first 4 relays?
-why are the 16 channels not dry contact but 24v?

Thanks for support]]> <![CDATA[KC868-E16T wiring diagram]]> https://www.kincony.com/forum/showthread.php?tid=3278 Tue, 19 Sep 2023 14:14:47 +0800 KinCony Support]]> https://www.kincony.com/forum/showthread.php?tid=3278
.jpg

.jpg

E16T.jpg (Size: 626.56 KB / Downloads: 1556) ]]> <![CDATA[KC868-E16T Factory Original Firmware added RF remote code]]> https://www.kincony.com/forum/showthread.php?tid=3170 Mon, 21 Aug 2023 10:09:11 +0800 admin]]> https://www.kincony.com/forum/showthread.php?tid=3170
firmware BIN file download:
.zip

E16T-RF-Tuya.zip (Size: 416.47 KB / Downloads: 944)

about ESP flash tool download link and details see here : https://www.kincony.com/esp-module-flash...tools.html

.png


arduino source code download:

.zip

E16T-Tuya-RF.zip (Size: 5.6 KB / Downloads: 913)

How does KC868-E16T learn wireless signals see here: https://www.kincony.com/forum/showthread.php?tid=3169

]]>
firmware BIN file download:
.zip

E16T-RF-Tuya.zip (Size: 416.47 KB / Downloads: 944)

about ESP flash tool download link and details see here : https://www.kincony.com/esp-module-flash...tools.html

.png


arduino source code download:

.zip

E16T-Tuya-RF.zip (Size: 5.6 KB / Downloads: 913)

How does KC868-E16T learn wireless signals see here: https://www.kincony.com/forum/showthread.php?tid=3169

]]> <![CDATA[How does KC868-E16T learn wireless signals]]> https://www.kincony.com/forum/showthread.php?tid=3169 Mon, 21 Aug 2023 10:05:40 +0800 KinCony Support]]> https://www.kincony.com/forum/showthread.php?tid=3169
.zip

E16T-test-2022_RF_study.zip (Size: 5.88 KB / Downloads: 732)

.jpg

.jpg

.zip

E16T-test-2022_RF_study.zip (Size: 5.88 KB / Downloads: 732)

.jpg

.jpg

key16.jpg (Size: 539.9 KB / Downloads: 1035) ]]> <![CDATA[How can Smart switch panel with rs485 with KC868-E16T and other product]]> https://www.kincony.com/forum/showthread.php?tid=2532 Sun, 22 Jan 2023 20:33:14 +0800 engmohades]]> https://www.kincony.com/forum/showthread.php?tid=2532 Attached is a picture and the attachment of the protocol

.jpg


.pdf

Switch RS 485 protocal.pdf (Size: 966.55 KB / Downloads: 9387) ]]> Attached is a picture and the attachment of the protocol

.jpg


.pdf

Switch RS 485 protocal.pdf (Size: 966.55 KB / Downloads: 9387) ]]> <![CDATA[KC868-E16T Factory Original Firmware for Tuya App]]> https://www.kincony.com/forum/showthread.php?tid=2421 Wed, 30 Nov 2022 10:02:49 +0800 admin]]> https://www.kincony.com/forum/showthread.php?tid=2421

.zip

KC868-E16T_tuya.nodemcu-32s.zip (Size: 116.22 KB / Downloads: 1000)

some people after downloaded ESPHome firmware for home assistant, if you want to use tuya app again, you can download the Factory Original Firmware for recovery.

about ESP flash tool download link and details see here : https://www.kincony.com/esp-module-flash...tools.html

need add 4 files,set the address like the picture

.png


.zip

111.png (Size: 42.17 KB / Downloads: 2809) ]]> <![CDATA[KC868-E16T demo configure for ESPhome]]> https://www.kincony.com/forum/showthread.php?tid=2318 Mon, 26 Sep 2022 22:03:22 +0800 admin]]> https://www.kincony.com/forum/showthread.php?tid=2318
.zip

Made_for_ESPHome_KC868-E16T.zip (Size: 887 bytes / Downloads: 1022)

esphome:
name: kc868-e16t
platform: ESP32
board: esp32dev

# Example configuration entry for ESP32
i2c:
sda: 16
scl: 15
scan: true
id: bus_a

# Example configuration entry
ethernet:
type: LAN8720
mdc_pin: GPIO23
mdio_pin: GPIO18
clk_mode: GPIO17_OUT
phy_addr: 0

# Optional manual IP
# manual_ip:
# static_ip: 192.168.1.199
# gateway: 192.168.1.1
# subnet: 255.255.255.0

# Example configuration entry
pcf8574:
- id: 'pcf8574_hub_out_1' # for output channel 1-8
address: 0x21

- id: 'pcf8574_hub_out_2' # for output channel 9-16
address: 0x25

- id: 'pcf8574_hub_in_1' # for input channel 1-8
address: 0x22

- id: 'pcf8574_hub_in_2' # for input channel 9-16
address: 0x24

# Individual outputs
switch:
- platform: gpio
name: "e16t-output1"
pin:
pcf8574: pcf8574_hub_out_1
number: 0
mode: OUTPUT
inverted: true

- platform: gpio
name: "e16t-output2"
pin:
pcf8574: pcf8574_hub_out_1
number: 1
mode: OUTPUT
inverted: true

- platform: gpio
name: "e16t-output3"
pin:
pcf8574: pcf8574_hub_out_1
number: 2
mode: OUTPUT
inverted: true

- platform: gpio
name: "e16t-output4"
pin:
pcf8574: pcf8574_hub_out_1
number: 3
mode: OUTPUT
inverted: true

- platform: gpio
name: "e16t-output5"
pin:
pcf8574: pcf8574_hub_out_1
number: 4
mode: OUTPUT
inverted: true

- platform: gpio
name: "e16t-output6"
pin:
pcf8574: pcf8574_hub_out_1
number: 5
mode: OUTPUT
inverted: true

- platform: gpio
name: "e16t-output7"
pin:
pcf8574: pcf8574_hub_out_1
number: 6
mode: OUTPUT
inverted: true

- platform: gpio
name: "e16t-output8"
pin:
pcf8574: pcf8574_hub_out_1
number: 7
mode: OUTPUT
inverted: true

- platform: gpio
name: "e16t-output9"
pin:
pcf8574: pcf8574_hub_out_2
number: 0
mode: OUTPUT
inverted: true

- platform: gpio
name: "e16t-output10"
pin:
pcf8574: pcf8574_hub_out_2
number: 1
mode: OUTPUT
inverted: true

- platform: gpio
name: "e16t-output11"
pin:
pcf8574: pcf8574_hub_out_2
number: 2
mode: OUTPUT
inverted: true

- platform: gpio
name: "e16t-output12"
pin:
pcf8574: pcf8574_hub_out_2
number: 3
mode: OUTPUT
inverted: true

- platform: gpio
name: "e16t-output13"
pin:
pcf8574: pcf8574_hub_out_2
number: 4
mode: OUTPUT
inverted: true

- platform: gpio
name: "e16t-output14"
pin:
pcf8574: pcf8574_hub_out_2
number: 5
mode: OUTPUT
inverted: true

- platform: gpio
name: "e16t-output15"
pin:
pcf8574: pcf8574_hub_out_2
number: 6
mode: OUTPUT
inverted: true

- platform: gpio
name: "e16t-output16"
pin:
pcf8574: pcf8574_hub_out_2
number: 7
mode: OUTPUT
inverted: true

binary_sensor:
- platform: gpio
name: "e16t-input1"
pin:
pcf8574: pcf8574_hub_in_1
number: 0
mode: INPUT
inverted: true

- platform: gpio
name: "e16t-input2"
pin:
pcf8574: pcf8574_hub_in_1
number: 1
mode: INPUT
inverted: true

- platform: gpio
name: "e16t-input3"
pin:
pcf8574: pcf8574_hub_in_1
number: 2
mode: INPUT
inverted: true

- platform: gpio
name: "e16t-input4"
pin:
pcf8574: pcf8574_hub_in_1
number: 3
mode: INPUT
inverted: true

- platform: gpio
name: "e16t-input5"
pin:
pcf8574: pcf8574_hub_in_1
number: 4
mode: INPUT
inverted: true

- platform: gpio
name: "e16t-input6"
pin:
pcf8574: pcf8574_hub_in_1
number: 5
mode: INPUT
inverted: true

- platform: gpio
name: "e16t-input7"
pin:
pcf8574: pcf8574_hub_in_1
number: 6
mode: INPUT
inverted: true

- platform: gpio
name: "e16t-input8"
pin:
pcf8574: pcf8574_hub_in_1
number: 7
mode: INPUT
inverted: true

- platform: gpio
name: "e16t-input9"
pin:
pcf8574: pcf8574_hub_in_2
number: 0
mode: INPUT
inverted: true

- platform: gpio
name: "e16t-input10"
pin:
pcf8574: pcf8574_hub_in_2
number: 1
mode: INPUT
inverted: true

- platform: gpio
name: "e16t-input11"
pin:
pcf8574: pcf8574_hub_in_2
number: 2
mode: INPUT
inverted: true

- platform: gpio
name: "e16t-input12"
pin:
pcf8574: pcf8574_hub_in_2
number: 3
mode: INPUT
inverted: true

- platform: gpio
name: "e16t-input13"
pin:
pcf8574: pcf8574_hub_in_2
number: 4
mode: INPUT
inverted: true

- platform: gpio
name: "e16t-input14"
pin:
pcf8574: pcf8574_hub_in_2
number: 5
mode: INPUT
inverted: true

- platform: gpio
name: "e16t-input15"
pin:
pcf8574: pcf8574_hub_in_2
number: 6
mode: INPUT
inverted: true

- platform: gpio
name: "e16t-input16"
pin:
pcf8574: pcf8574_hub_in_2
number: 7
mode: INPUT
inverted: true

# Enable logging
logger:

# Enable Home Assistant API
api:]]>
.zip
