KC868-H32B blinds motor control and connect - Autotec2022 - 07-03-2022 Hello Can you help with connection and adjustment of all motor blinds on the house I have 22 shutter motors i want to connect everything to KC868-H32B I bought two pieces Order ID: 8151334628020945 Order ID: 8151122210730945 The engine model I own are Solus 2PA https://www.somfy.co.in/products/1032574/solus-2-pa-6-12-pack-100 I need help with connecting the wires because I won't have a button to control the blinds, but all the motors are connected directly to the KC868-H32B, the control is only done using the app. In order not to damage the relay by wrong connection, you can send me some instructions and information. I have see that diagram but im not understand https://ibb.co/nChbVM3 Im not understand becuse i have think that all motors get power from the relay KC868-H32B or i must bring power cable N L direkt on motors RE: KC868-H32B blinds motor control and connect - admin - 07-04-2022 can you draw a photo on the paper, tell me your motor's wire define? then give you a solution. if you want to add manual control buttons, you can add "switch terminal board", it have " motor" work mode, use every 2 relay for one motor work for "UP" , "DOWN" , "STOP". RE: KC868-H32B blinds motor control and connect - Autotec2022 - 07-04-2022 (07-04-2022, 01:16 AM)admin Wrote: can you draw a photo on the paper, tell me your motor's wire define? then give you a solution. if you want to add manual control buttons, you can add "switch terminal board", it have " motor" work mode, use every 2 relay for one motor work for "UP" , "DOWN" , "STOP". Pictures are attached https://ibb.co/WW5D8K7 I have put red circle for information that i WILL NOT have swith or any phisycal button . All motors will control VIA wifi APP Solus motors information - https://service.somfy.com/downloads/in_v5/leafsolus_pa_5003964b_ig.pdf RE: KC868-H32B blinds motor control and connect - admin - 07-04-2022 1. if you use home assistant software, you just set interlock mode in home assistant. 2. if you use "kincony smart home" app directly. you need to do two step. A. every two channel relay will control one motor. let two relay's COM connect with "L" together, then relay-1 output connect with motor-"2", relay-2 connect with motor-"3" B. make "scene mode" in "kincony smart home" app, every scene mode such as "relay1 ON, relay2 OFF" and "relay1 OFF, relay2 ON", "relay1 OFF, relay2 OFF" for motor UP, motor DOWN, motor STOP. here are some customer's case video you can see: https://www.youtube.com/watch?v=5MFgB6RFsMU&list=PLQUWhE_6LeOQnNP0vqwN7Kcjva3oDYfSM&index=9 https://www.youtube.com/watch?v=e1khSbs5E6Q&list=PLQUWhE_6LeOQnNP0vqwN7Kcjva3oDYfSM&index=10 https://www.youtube.com/watch?v=h7Vg_2tUNxc&list=PLQUWhE_6LeOQnNP0vqwN7Kcjva3oDYfSM&index=11 https://www.youtube.com/watch?v=t52qUpaBdZs&list=PLQUWhE_6LeOQnNP0vqwN7Kcjva3oDYfSM&index=12 RE: KC868-H32B blinds motor control and connect - Autotec2022 - 07-04-2022 (07-04-2022, 01:02 PM)admin Wrote: 1. if you use home assistant software, you just set interlock mode in home assistant. Ok, Thank You When i have all connect i will adjust all and send a video. RE: KC868-H32B blinds motor control and connect - admin - 07-04-2022 yes, it's ok. RE: KC868-H32B blinds motor control and connect - mnichu - 11-17-2022 my configuration if someone need... for Home Assistant interlock in my case set to 1 second but it possible to set 100;200;300 millisecond or something simmilar Template for cover (for configuration.yaml or separate name_file.yaml): switch.relay1c - shutter down switch.relay2c -shutter up Code: cover: entity card : ( "Paper Buttons Row" from HACS required) Code: type: entities Time for open and close shutters i have setting direct in KC868-H32B. Result: Enjoy RE: KC868-H32B blinds motor control and connect - admin - 11-17-2022 good job, thanks. RE: KC868-H32B blinds motor control and connect - JoeM - 12-21-2022 Hello everyone, I have 13 blind motors to drive, 1 garage door and 1 fence door. I bought 1 H32BS and 2xE16. The intention is to use press wall switches and home assistant (in a later stage - still not installed). What is the connection scheme and what adjustments need to be done on H32BS? Thanks. RE: KC868-H32B blinds motor control and connect - admin - 12-22-2022 usually two relay work with one motor, now H32BS the newest firmware have added "interlock" option for motor, that is useful for motor and protect motor. make sure you can update to firmware v1.50SP. here is download link: https://www.kincony.com/forum/showthread.php?tid=2455 |
