Heart [Arduino demo source code for KC868-A4]-09 homekit work with 2 relay
Posted by: KinCony Support - 01-07-2022, 05:19 AM - Forum: KC868-A4 - No Replies

Code 8: //The demo code is homekit    You can copy the code to your Arduino IDE.

Code:
#include "HomeSpan.h"
#include "DEV_LED.h"          // NEW! Include this new file, DEV_LED.h, which will be fully explained below

void setup() {
  Serial.begin(115200);

  homeSpan.begin(Category::Lighting,"HomeSpan LEDs");

  new SpanAccessory();

    new Service::AccessoryInformation();
      new Characteristic::Name("LED #1");
      new Characteristic::Manufacturer("HomeSpan");
      new Characteristic::SerialNumber("123-ABC");
      new Characteristic::Model("20mA LED");
      new Characteristic::FirmwareRevision("0.9");
      new Characteristic::Identify();

    new Service::HAPProtocolInformation();
      new Characteristic::Version("1.1.0");

  new SpanAccessory();

    new Service::AccessoryInformation();
      new Characteristic::Name("LED #2");
      new Characteristic::Manufacturer("HomeSpan");
      new Characteristic::SerialNumber("123-ABC");
      new Characteristic::Model("20mA LED");
      new Characteristic::FirmwareRevision("0.9");
      new Characteristic::Identify();

    new Service::HAPProtocolInformation();
      new Characteristic::Version("1.1.0");

    new DEV_LED(15);                                  // ...and replaced with a single line that instantiates a second DEV_LED Service on Pin 17

}

void loop(){

  homeSpan.poll();

}

.zip   homekit.zip (Size: 6.28 KB / Downloads: 1036)

Print this item

Heart [Arduino demo source code for KC868-A4]-08 control relay by BlueTooth
Posted by: KinCony Support - 01-07-2022, 05:12 AM - Forum: KC868-A4 - No Replies

Code 7: //The demo code is Bluetooth    You can copy the code to your Arduino IDE.

Code:
#include "BluetoothSerial.h"

// init Class:
BluetoothSerial ESP_BT;

// init PINs: assign any pin on ESP32
int Relay1 = 2;
int Relay2 = 15;
int Relay3 = 5;
int Relay4 = 4;

// Parameters for Bluetooth interface
int incoming;

void setup() {
  ESP_BT.begin("KC868-A4-BlueTooth"); //Name of your Bluetooth interface -> will show up on your phone

  pinMode (Relay1, OUTPUT);
  pinMode (Relay2, OUTPUT);
  pinMode (Relay3, OUTPUT);
  pinMode (Relay4, OUTPUT);
}


void loop() {

  // -------------------- Receive Bluetooth signal ----------------------
  if (ESP_BT.available())
  {
    incoming = ESP_BT.read(); //Read what we receive

    // separate button ID from button value -> button ID is 10, 20, 30,40 etc, value is 1 or 0
    //Relay1 ON:11  OFF:10
    //Relay2 ON:21  OFF:20
    //Relay3 ON:31  OFF:30
    //Relay4 ON:41  OFF:40
    int button = floor(incoming / 10);
    int value = incoming % 10;

    switch (button) {
      case 1:
        digitalWrite(Relay1, value);
        break;
      case 2:
        digitalWrite(Relay2, value);
        break;
      case 3:
        digitalWrite(Relay3, value);
        break;
      case 4:
        digitalWrite(Relay4, value);
        break;
    }
  }
}
Print this item

Heart [Arduino demo source code for KC868-A4]-07 voice control by alexa speaker
Posted by: KinCony Support - 01-07-2022, 03:13 AM - Forum: KC868-A4 - Replies (2)

Code 6: //The demo code is Alexa control     You can copy the code to your Arduino IDE

Code:
#ifdef ARDUINO_ARCH_ESP32
#include <WiFi.h>
#else
#include <ESP8266WiFi.h>
#endif
#include <Espalexa.h>

#define Relay1 2
#define Relay2 15
#define Relay3 5
#define Relay4 4

// prototypes
boolean connectWifi();

//callback functions
void F1LightChanged(uint8_t brightness);
void F2LightChanged(uint8_t brightness);
void F3LightChanged(uint8_t brightness);
void F4LightChanged(uint8_t brightness);

// Change this!!

// WiFi Credentials
const char* ssid = "KinCony";           //input your router's SSID
const char* password = "a12345678";    // input your router's password

// device names
String Device_1_Name = "Yellow light";
String Device_2_Name = "Green light";
String Device_3_Name = "Blue light";
String Device_4_Name = "Red light";


boolean wifiConnected = false;

Espalexa espalexa;

void setup()
{
  Serial.begin(115200);
  pinMode(Relay1, OUTPUT);
  pinMode(Relay1, LOW);

  pinMode(Relay2, OUTPUT);
  pinMode(Relay2, LOW);

  pinMode(Relay3, OUTPUT);
  pinMode(Relay3, LOW);

  pinMode(Relay4, OUTPUT);
  pinMode(Relay4, LOW);

  // Initialise wifi connection
  wifiConnected = connectWifi();

  if (wifiConnected)
  {
    // Define your devices here.
          espalexa.addDevice(Device_1_Name,F1LightChanged);
          espalexa.addDevice(Device_2_Name,F2LightChanged);
          espalexa.addDevice(Device_3_Name,F3LightChanged);
          espalexa.addDevice(Device_4_Name,F4LightChanged);

    espalexa.begin();

  }

  else
  {
    while (1)
    {
      Serial.println("Cannot connect to WiFi. Please check data and reset the ESP.");
      delay(2500);
    }
  }

}

void loop()
{
  espalexa.loop();
  delay(1);
}

//our callback functions
void F1LightChanged(uint8_t brightness)
{
  //Control the device
  if (brightness)
  {
    if (brightness == 255)
    {
      digitalWrite(Relay1,HIGH);
    }

  }
  else
  {
   digitalWrite(Relay1, LOW);
  }
}

void F2LightChanged(uint8_t brightness)
{

  //Control the device
  if (brightness)
  {
    if (brightness == 255)
    {
      digitalWrite(Relay2,HIGH);
    }

  }
  else
  {
   digitalWrite(Relay2,LOW);
  }
}

void F3LightChanged(uint8_t brightness)
{

  //Control the device
  if (brightness)
  {
    if (brightness == 255)
    {
     digitalWrite(Relay3,HIGH);
    }
  }
  else
  {
     digitalWrite(Relay3,LOW);
  }
}

void F4LightChanged(uint8_t brightness)
{

  //Control the device
  if (brightness)
  {
    if (brightness == 255)
    {
     digitalWrite(Relay4,HIGH);
    }
  }
  else
  {
    digitalWrite(Relay4,LOW);
  }
}



// connect to wifi – returns true if successful or false if not
boolean connectWifi()
{
  boolean state = true;
  int i = 0;

  WiFi.mode(WIFI_STA);
  WiFi.begin(ssid, password);

  // Wait for connection
  Serial.print("Connecting...");
  while (WiFi.status() != WL_CONNECTED) {
    delay(500);
    Serial.print(".");
    if (i > 20) {
      state = false; break;
    }
    i++;
  }
  Serial.println("");
  if (state) {
    Serial.print("Connected to ");
    Serial.println(ssid);
    Serial.print("IP address: ");
    Serial.println(WiFi.localIP());
  }
  else {
    Serial.println("Connection failed.");
  }
  return state;
}



Attached Files Thumbnail(s)

Print this item

Heart [Arduino demo source code for KC868-A4]-06 analog output (DAC) data
Posted by: KinCony Support - 01-07-2022, 02:58 AM - Forum: KC868-A4 - No Replies

Code 5: //The demo code is DAC    You can copy the code to your Arduino IDE

Code:
#define DAC1 26   //DAC1 IO26
//#define DAC2 25   //DAC2 IO25

void setup() {

}

void loop() {
  int Value = 127; //255= 10V

  dacWrite(DAC1, 1);
  delay(500);
  dacWrite(DAC1, 50);
  delay(500);
  dacWrite(DAC1, 100);
  delay(500);
  dacWrite(DAC1, 150);
  delay(500);
  dacWrite(DAC1, 255);
  delay(500);
}


Print this item

Heart [Arduino demo source code for KC868-A4]-05 read analog input (ADC) data
Posted by: KinCony Support - 01-07-2022, 02:42 AM - Forum: KC868-A4 - No Replies

Code 4: //The demo code is ADC INPUT    You can copy the code to your Arduino IDE

Code:
#define ANALOG_PIN_32   32      //INA1  CH5

// #define ANALOG_PIN_33   33   //INA2  CH4
// #define ANALOG_PIN_34   34   //INA3  CH6
// #define ANALOG_PIN_35   35   //INA4  CH7


void setup(){
  Serial.begin(115200);
  pinMode(ANALOG_PIN_32,INPUT);
}

void loop() {
  int analog_value = 0;
  analog_value = analogRead(ANALOG_PIN_32);   //0--4096
  delay(1000);
  Serial.printf("Current Reading on Pin(%d)=%d\n",ANALOG_PIN_32,analog_value);
}


Print this item

Heart [Arduino demo source code for KC868-A4]-04 read DS18B20 temperature sensor
Posted by: KinCony Support - 01-07-2022, 02:21 AM - Forum: KC868-A4 - No Replies

Code 3: //The demo code is DS18B20    You can copy the code to your Arduino IDE

Code:
#include <DS18B20.h>

#define LOW_ALARM 20
#define HIGH_ALARM 25

DS18B20 ds(13);   //IO13

void setup() {
  Serial.begin(9600);

  while (ds.selectNext()) {
    ds.setAlarms(LOW_ALARM, HIGH_ALARM);
  }
}

void loop() {
  ds.doConversion();

  while (ds.selectNextAlarm()) {
    Serial.print("Alarm Low: ");
    Serial.print(ds.getAlarmLow());
    Serial.println(" C");
    Serial.print("Alarm High: ");
    Serial.print(ds.getAlarmHigh());
    Serial.println(" C");
    Serial.print("Temperature: ");
    Serial.print(ds.getTempC());
    Serial.println(" C\n");
  }

  delay(1000);
}


Print this item

Heart [Arduino demo source code for KC868-A4]-03 send 433MHz RF signal
Posted by: KinCony Support - 01-07-2022, 02:18 AM - Forum: KC868-A4 - No Replies

Code 2: //The demo code is RF-send  You can copy the code to your Arduino IDE

Code:
#include <RCSwitch.h>

RCSwitch mySwitch = RCSwitch();

void setup() {

  Serial.begin(9600);
    mySwitch.enableTransmit(21);  // IO21
  }

void loop() {

  /* See Example: TypeA_WithDIPSwitches */
  mySwitch.switchOn("11111", "00010");
  delay(1000);
  mySwitch.switchOff("11111", "00010");
  delay(1000);

  /* Same switch as above, but using decimal code */
  mySwitch.send(5393, 24);
  delay(1000);
  mySwitch.send(5396, 24);
  delay(1000);

  /* Same switch as above, but using binary code */
  mySwitch.send("000000000001010100010001");
  delay(1000);
  mySwitch.send("000000000001010100010100");
  delay(1000);

  /* Same switch as above, but tri-state code */
  mySwitch.sendTriState("00000FFF0F0F");
  delay(1000);
  mySwitch.sendTriState("00000FFF0FF0");
  delay(1000);

  delay(20000);
}


Print this item

Heart [Arduino demo source code for KC868-A4]-02 433MHz RF signal receive decode
Posted by: KinCony Support - 01-07-2022, 02:13 AM - Forum: KC868-A4 - No Replies

Code 1: //The demo code is RF-receive    You can copy the code to your Arduino IDE

Code:
#include <RCSwitch.h>

RCSwitch mySwitch = RCSwitch();

void setup() {
  Serial.begin(9600);
  mySwitch.enableReceive(digitalPinToInterrupt(19));  //IO19
  Serial.print("begin test");
}

void loop() {
  if (mySwitch.available()) {

    Serial.print("Received ");
    Serial.print( mySwitch.getReceivedValue() );
    Serial.print(" / ");
    Serial.print( mySwitch.getReceivedBitlength() );
    Serial.print("bit ");
    Serial.print("Protocol: ");
    Serial.println( mySwitch.getReceivedProtocol() );

    mySwitch.resetAvailable();
  }
}


Print this item

Heart [Arduino demo source code for KC868-A4]-01 config Arduino IDE for ESP32 module
Posted by: KinCony Support - 01-07-2022, 02:06 AM - Forum: KC868-A4 - No Replies

 Before using KC868-A4, you need to set the parameters of the preference

Copy the following URL:https://dl.espressif.com/dl/package_esp32_index.json

.pdf   KC868-A4-schematic.pdf (Size: 244.64 KB / Downloads: 1331)

Print this item

  KC868-D8 V4.37 new firmware update
Posted by: admin - 01-06-2022, 12:03 PM - Forum: News - Replies (5)

improvement:

when switch button work in "1 Key" mode . we let the "UP" and "DOWN" button ports with the same function. so that easy for connect two thick wire from two different places. such as this two thick wire not easy connect to one terminal pole.



update BIN file firmware by "KC868 Controller Network Bootloader" tool.

[Image: KC868-Controller-Network-Bootloader.png]
KC868 Controller Network Bootloader

[Image: zip.png]   KC868 Controller Network Bootloader.zip

firmware BIN file

.zip   Dimmer8_V437_0106.zip (Size: 45.49 KB / Downloads: 1099)

Print this item
