SDA:GPIO8
SCL:GPIO18

PCF8575: (input1-16): i2c address:0x22 by B16-core

P8:input1
P9:input2
P10:input3
P11:input4
P12:input5
P13:input6
P14:input7
P15:input8

P0:input9
P1:input10
P2:input11
P3:input12
P4:input13
P5:input14
P6:input15
P7:input16

ADS1115 (4CH ADC): i2c address:0x48
Analog input (A1: DC 0-5v)
Analog input (A2: DC 0-5v)
Analog input (A3: DC 4-20mA)
Analog input (A4: DC 4-20mA)

24C02 EPROM i2c address: 0x50
DS3231 RTC i2c address: 0x68

1-wire (pull-up resistance on PCB):
1-wire1:GPIO47
1-wire2:GPIO48
1-wire3:GPIO7
1-wire4:GPIO40

free GPIOs:
GPIO13
GPIO14
GPIO21

-----------------------
Ethernet (W5500) I/O define:

clk_pin: GPIO1
mosi_pin: GPIO2
miso_pin: GPIO41
cs_pin: GPIO42

interrupt_pin: GPIO43
reset_pin: GPIO44

--------------------
RS485:
RXD:GPIO38
TXD:GPIO39

Tuya module:
RXD:GPIO17
TXD:GPIO16

Tuya network button: Tuya module's P28
Tuya network LED: Tuya module's P16

ARM CPU TXD:GPIO4
ARM CPU RXD:GPIO6

SD Card:
SPI-MOSI:GPIO10
SPI-SCK:GPIO11
SPI-MISO:GPIO12
SPI-CS:GPIO9
SD-Detect: GPIO5

v3.12.0 improvement:
1. Adapt to new KinCony Controller: B8/B8M/B24/B24M/DM16
2. Sensor pull-up option: When PCB include pull-up resistor, "pull-up" will auto shown as enabled
3. Network webpage -- LAN mode will show the actual ethernet IP address
4. GSM phone list: Add ID numbers
5. Password-related inputs option added masking
6. Sensor configuration webpage: added sensor name
7. IFTTT "sensor channel" change to "sensor name" have preset
8. Removed default MQTT port number "1883"
9. IFTTT THEN actions: Add "step value" for AO (analog output)
10. improve previous version first time downloaded firmware boot up speed slowly issue.

Attached Files

  KCS_A2V3_V3.12.0.zip (Size: 1.07 MB / Downloads: 298)
  KCS_A6V3_V3.12.0.zip (Size: 1.04 MB / Downloads: 305)
  KCS_A8V3_V3.12.0.zip (Size: 1.09 MB / Downloads: 293)
  KCS_A16V3_V3.12.0.zip (Size: 1.11 MB / Downloads: 357)
  KCS_A32PRO_V3.12.0.zip (Size: 1.08 MB / Downloads: 269)
  KCS_AG8_V3.12.0.zip (Size: 1.06 MB / Downloads: 245)
  KCS_ALR_V3.12.0.zip (Size: 1.02 MB / Downloads: 259)
  KCS_B8_V3.12.0.zip (Size: 1.1 MB / Downloads: 255)
  KCS_B8M_V3.12.0.zip (Size: 1.1 MB / Downloads: 282)
  KCS_B16_V3.12.0.zip (Size: 1.1 MB / Downloads: 253)
  KCS_B16M_V3.12.0.zip (Size: 1.1 MB / Downloads: 247)
  KCS_B24_V3.12.0.zip (Size: 1.1 MB / Downloads: 234)
  KCS_B24M_V3.12.0.zip (Size: 1.1 MB / Downloads: 255)
  KCS_DM16_V3.12.0.zip (Size: 1.07 MB / Downloads: 245)
  KCS_F8_V3.12.0.zip (Size: 1.09 MB / Downloads: 255)
  KCS_F16_V3.12.0.zip (Size: 1.1 MB / Downloads: 262)
  KCS_F24_V3.12.0.zip (Size: 1.1 MB / Downloads: 249)
  KCS_G1_V3.12.0.zip (Size: 1.06 MB / Downloads: 253)
  KCS_KC_TA_V3.12.0.zip (Size: 1.05 MB / Downloads: 219)
  KCS_N60_V3.12.0.zip (Size: 986.2 KB / Downloads: 268)
  KCS_T16M_V3.12.0.zip (Size: 1.05 MB / Downloads: 257)
  KCS_T32M_V3.12.0.zip (Size: 1.07 MB / Downloads: 258)
  KCS_T64M_V3.12.0.zip (Size: 1.07 MB / Downloads: 254)
  KCS_T128M_V3.12.0.zip (Size: 1.07 MB / Downloads: 248)
  KCS_Z1_V3.12.0.zip (Size: 1.21 MB / Downloads: 272)

I have a kc868-h32b I can log in to the webpanel just fine with ethernet and I can see it has firmware H32B_Pro_V1.19

I can connect the USB-C to my windows 10 machine. And it shows up as COM4.
I can click "OPEN PORT" as soon as the device restarts
But when I click on the bootloader detect button nothing happens

I've tried restarting the device more than 50 times. With varying timings and Baudrates. But no change. I never get the results shown in the youtube video

How do I debug this, what am I doing wrong?
Is the USB C version different than what is shown in the video?

Attached Files

Thumbnail(s)


Can you provide a solution to utilise the KC868-D 8 and 16 channel dimmer over KC868-HAv2 RS485 interface
I would like to use multiple KC868-HAv2 (8 of them) connecting over RS485 to the Dimming module and all to the F16 device

I want to use some of the switch paddles for the dimmer and others to switch the outputs on the F16.
thanks

rpiboot_setup.exe for CM5 lite USB driver.

  rpiboot_setup.zip (Size: 32.75 MB / Downloads: 283)

Hi,

Could you please post a picture of the cct for the GPIOs 13 14 and 40 pls. I will be configuring one of these as an output.

I want to interface it to a 24v Flow meter that has a reset line when pulled low.

Thank you

Hello. can you tell me how I can connect the esprog debugger(jtag) to this board?  I have a problem with pin io15 (TDO), which is powered by 3v all the time, and it seems to me that this is interfering with debugging. Of course, I can cut the track for debugging time. But as a novice developer, I am tormented by the question: How did you debug on this board via JTAG? I don't want to use printf()
If this information is not for general use, then please reply by email or in private messages.

Attached Files

Image(s)


Hi,

I am seeking technical advice and consultation on determining which specific Kincony controllers and how many units would be required for my smart home project.

Controllers should be based on ESP32 platform and preferably support the newer Kincony KCS v3 firmware version.
I am looking for a complete system solution to meet my requirements.

PROJECT SPECIFICATIONS:

INPUTS:
- 67× lighting control inputs (momentary/impulse switches)
- 12× shutter control inputs (up + down commands)
- 14× window/door contact sensors
- 10× digital sensor inputs (human presence sensor, valves, etc.)
- 14× temperature sensor inputs (analog, including 4× temperature+humidity sensors, max distance is ~20m; planned DS18B20/DHT22 but the wiring is star-shaped, so can it be done with 1-wire?)

OUTPUTS:
- 34× lighting outputs (AC 230V)
- 10× LED lighting outputs (DC 24V white + dimmers)
- 12× shutter motor outputs
- 12× floor heating electrovalve control outputs

Thank you in advance for your time and expertise.

I have a Kincony KC868 A16 board and want to control a stepper motor with variable speed.

I have connected the board up to the stepper motor driver, software works with another ESP32 board.

But I do not get a pulses out of the GPIO pins.

Do I need to set any other parameters to get the pulses out of the GPIO pins ?

Thanks

I am using KC868-A16 to control the lighting system and sensors in my house. I see in the documentation that there are instructions on MQTT, but I am not sure if any special configuration (such as firmware adjustment or setting up a separate broker) is required to integrate stably with Home Assistant. In addition, has anyone tested latency or disconnection issues when using MQTT with the KC868-A series?
I hope everyone can share their experiences.
