  [arduino code examples for N30]-05 collect N30 all data demo
Posted by: admin - 08-03-2025, 03:27 AM - Forum: N30 - No Replies

Code:
/*
* Made by KinCony IoT: https://www.kincony.com
*
* Demo Program for Reading Data from KinCony N60 Energy Meter (60-channel version)
* via RS485 Modbus using ESP32 and NonBlockingModbusMaster library.
*
* This example:
* - Initializes RS485 Modbus communication
* - Reads current, power, energy, voltage, frequency, temperature, power factor from 6 chips
* - Prints all data to Serial Monitor
* - Uses TaskScheduler to run periodic tasks
*/

#include "TaskScheduler.h"
#include "HardwareSerial.h"
//#include "modbus-rtu.h"
#include "NonBlockingModbusMaster.h"  // Include non-blocking Modbus master library

/////defined anything here====================
#define MAX_U16DATA_LEN  68  // Number of 16-bit registers to read per chip

// Define RS485 serial and control pins
#define TX_PIN 8
#define DE_PIN 3
#define RX_PIN 18

// Define Modbus function codes
typedef enum{
  FC_READ_COIL = 1,
  FC_READ_HOLDREG = 3,
  FC_READ_INPUTREG = 4,
  FC_FORCE_COIL = 5,
  FC_FORCE_COILS = 15,
  FC_WRITE_REG = 6,
  FC_WRITE_REGS = 16,
}FC_DEF;

// Define structure to hold all the electrical parameters per chip
typedef struct
{
    uint32_t RMS_1;        //0    //XX.XXX    A        0.001A/LSB
    uint32_t RMS_2;
    uint32_t RMS_3;
    uint32_t RMS_4;
    uint32_t RMS_5;
    uint32_t RMS_6;
    uint32_t RMS_7;
    uint32_t RMS_8;
    uint32_t RMS_9;
    uint32_t RMS_10;
    uint32_t WATT_1;        //20 XXXX.X    W        0.1W/LSB
    uint32_t WATT_2;
    uint32_t WATT_3;
    uint32_t WATT_4;
    uint32_t WATT_5;
    uint32_t WATT_6;
    uint32_t WATT_7;
    uint32_t WATT_8;
    uint32_t WATT_9;
    uint32_t WATT_10;//
    uint32_t Energy_1;        //40 XXXXXX    kWh   1kWh/LSB,MAX:65535kWh
    uint32_t Energy_2;
    uint32_t Energy_3;
    uint32_t Energy_4;
    uint32_t Energy_5;
    uint32_t Energy_6;
    uint32_t Energy_7;
    uint32_t Energy_8;
    uint32_t Energy_9;
    uint32_t Energy_10; //
    uint32_t Energy_Sum; //60
    uint16_t RMS_V;            //62 XXX.X    V            0.01V/LSB
    uint16_t Period;        //63 XX.XX    Hz        0.01Hz/LSB
    float TPS1;            //64 XX.XX ℃            0.1℃/LSB
    float PF;  //66
}Elect_StructDef_JKE;

typedef union{
  Elect_StructDef_JKE jke_n60_str[6]; ////6 chips each have MAX_STRU_LEN data
  ushort read_regs_arr[6][MAX_U16DATA_LEN];
}COLLECT_UNION;

////define instance here================================================================
COLLECT_UNION jke_n60_data_union = {0};
HardwareSerial collectSerial(2);
Scheduler ts;   // Task scheduler
NonBlockingModbusMaster nbModbusMaster;

////define macros here===================
static void collectAllChipData();
static void PrintfInfo();

////define my work task==================================
Task collectDataTask(200,TASK_FOREVER,[]()
{
  collectAllChipData();
});

Task heartBeatTask(1000,TASK_FOREVER,[]()
{
  ////do anything in heartBeatTask to make sense for anyone or other.
  Serial.println("heartbeat task is running.");
});


void setup() {
  // put your setup code here, to run once:

  // Open serial communications and wait for port to open:
    Serial.begin(115200);
    collectSerial.begin(115200,SERIAL_8N1,9,10);///RX & TX
    float bitduration = 1.f / 115200;
    float charlen = 10.0f; // 8 bits + 1 stop, parity ?
    float preDelayBR = bitduration * charlen * 3.5f * 1e6  + 1; // in us
    float postDelayBR = bitduration * charlen * 3.5f * 1e6 + 1; // in us
    nbModbusMaster.initialize(collectSerial, preDelayBR, postDelayBR,1000);

  ////add task to scheduler
  ts.addTask(collectDataTask);
  ts.addTask(heartBeatTask);

  ////start task
  collectDataTask.enable(); ///start task
  heartBeatTask.enable();
}

bool isMbConnect = false;
int cnt_chip = 0;

void loop() {
  static int retryCount = 0;
  // put your main code here, to run repeatedly:
  ts.execute();

  if (nbModbusMaster.justFinished())
  {

    // check for errors
    int err = nbModbusMaster.getError(); // 0 for OK
    if (err) {
      isMbConnect = false;
      Serial.print("Error: "); nbModbusMaster.printHex(err, Serial); Serial.println();
      if ((err == nbModbusMaster.ku8MBResponseTimedOut) ) {
        retryCount++;
        Serial.println("Mbtask Retry");
        nbModbusMaster.retry(); // send same cmd again
      }
    } else {
      retryCount = 0; // success
    }
    if (err == 0) {
      isMbConnect = true;
      if(cnt_chip==5)
      {
        PrintfInfo();
      }

      for (int i = 0; i < nbModbusMaster.getResponseBufferLength(); i++) {
        jke_n60_data_union.read_regs_arr[cnt_chip][i] = nbModbusMaster.getResponseBuffer(i);
        //nbModbusMaster.printHex(nbModbusMaster.getResponseBuffer(i), Serial); Serial.print(" ");
      }

      cnt_chip++;
      if(cnt_chip >= 6) cnt_chip = 0;

    }
  }

}

static void PrintfInfo()
{
  char send_buf[100] = {0};
  uint32_t *ptr;
  uint16_t *ptr2;
  float *ptr3;

  memset(send_buf,0,100);
    ///// PRINTF ALL DATA READ FROM CHIP REGISTER.

    for(int j=0;j<6;j++)
    {
    sprintf(send_buf,">>chip/socket : %d Info:",j+1);
    Serial.println(send_buf);

    ptr= &jke_n60_data_union.jke_n60_str[j].RMS_1;
    ptr2 = &jke_n60_data_union.jke_n60_str[j].RMS_V;
    ptr3 = &jke_n60_data_union.jke_n60_str[j].TPS1;

    for(int i=0;i<35;i++)
    {
      if(i < 10)
      {
        sprintf(send_buf,"RMS_%d:    %.2f A,",i+1,*(ptr+i) * 0.001);
        Serial.println(send_buf);
      }
      else if(i < 20)
      {
        sprintf(send_buf,"WATT_%d:    %.2f W,",i+1-10,*(ptr+i) * 0.1);
        Serial.println(send_buf);
      }
      else if(i < 30)
      {
        sprintf(send_buf,"Energy_%d:    %d kWh,",i+1-20,*(ptr+i) );
        Serial.println(send_buf);
      }
      else if(i == 30)
      {
        sprintf(send_buf,"Energy_sum:    %d kWh,",*(ptr+i) );
        Serial.println(send_buf);
        memset(send_buf,0,100);
      }
      else if(i == 31)
      {
        sprintf(send_buf,"RMS_V:    %.2f V,",*ptr2 *0.01); ///62
        Serial.println(send_buf);
        memset(send_buf,0,100);
      }
      else if(i == 32)
      {
        sprintf(send_buf,"Period:    %.2f Hz,",*(ptr2+1) *0.01);
        Serial.println(send_buf);
        memset(send_buf,0,100);
      }
      else if(i == 33)
      {
        sprintf(send_buf,"Chip_Temp:    %.1f ^C,",*ptr3  );
        Serial.println(send_buf);
        memset(send_buf,0,100);
      }
      else if(i == 34)
      {
        sprintf(send_buf,"PF:    %.4f .",*(ptr3+1) );
        Serial.println(send_buf);
        memset(send_buf,0,100);
      }
    }

    if(j==5)
      Serial.println(">>Data Finished!>>");

  }
}

static void collectAllChipData()
{
  int read_addr_start = (cnt_chip+1) * 100;

  String str = "";
  uint16_t size = MAX_U16DATA_LEN;

  nbModbusMaster.readHoldingRegisters(1, read_addr_start, size);

}
arduino ino file download:

.zip   collect_n60_data_demo.zip (Size: 2.45 KB / Downloads: 323)
BIN file (you can use esp32 download tool download to ESP32-S3 with address 0x0 then directly to use) download:

.zip   collect_n60_data_demo.ino.merged.zip (Size: 189.94 KB / Downloads: 321)

before run the code, you need to install NonBlockingModbusMaster arduino library.


modify library .h file replace the number as photo.


after running code, will print all data by USB port:
Code:
y_5:    0 kWh,
Energy_6:    0 kWh,
Energy_7:    0 kWh,
Energy_8:    0 kWh,
Energy_9:    0 kWh,
Energy_10:    0 kWh,

RMS_V:    233.58 V,
Period:    49.70 Hz,
Chip_Temp:    25.5 ^C,
PF:    0.0000 .
>>Data Finished!>>
heartbeat task is running.
