[Arduino source code for KC868-A16S]-05 LAN8720_UDP

Posted by: KinCony Support - 04-14-2023, 02:46 AM - Forum: KC868-A16S - No Replies

Code:
#include <ETH.h>

#include <WiFiUdp.h>

#define ETH_ADDR        0

#define ETH_POWER_PIN  -1

#define ETH_MDC_PIN    23

#define ETH_MDIO_PIN   18

#define ETH_TYPE       ETH_PHY_LAN8720

#define ETH_CLK_MODE   ETH_CLOCK_GPIO17_OUT

WiFiUDP Udp;                      //Create UDP object

unsigned int localUdpPort = 4196; //local port

// Set it based on the IP address of the router

IPAddress local_ip(192, 168, 1, 200);

IPAddress gateway(192, 168, 1, 1);

IPAddress subnet(255, 255, 255, 0);

IPAddress dns(192, 168, 1, 1);

void setup()

{

  Serial.begin(115200);

  Serial.println();

  ETH.begin(ETH_ADDR, ETH_POWER_PIN, ETH_MDC_PIN, ETH_MDIO_PIN, ETH_TYPE, ETH_CLK_MODE); //start with ETH

  // write confir for static IP, gateway,subnet,dns1,dns2

  if (ETH.config(local_ip, gateway, subnet, dns, dns) == false) {

    Serial.println("LAN8720 Configuration failed.");

  }else{Serial.println("LAN8720 Configuration success.");}

 /* while(!((uint32_t)ETH.localIP())) //wait for IP

  {

  }*/

  Serial.println("Connected");

  Serial.print("IP Address:");

  Serial.println(ETH.localIP());

  Udp.begin(localUdpPort); //begin UDP listener

}

void loop()

{

  int packetSize = Udp.parsePacket(); //get package size

  if (packetSize)                     //if have received data

  {

    char buf[packetSize];

    Udp.read(buf, packetSize); //read current data

    Serial.println();

    Serial.print("Received: ");

    Serial.println(buf);

    Serial.print("From IP: ");

    Serial.println(Udp.remoteIP());

    Serial.print("From Port: ");

    Serial.println(Udp.remotePort());

    Udp.beginPacket(Udp.remoteIP(), Udp.remotePort()); //ready to send data

    Udp.print("Received: ");

    Udp.write((const uint8_t*)buf, packetSize); //copy data to sender buffer

    Udp.endPacket();            //send data

  }

}

[Arduino source code for KC868-A16S]-05 LAN8720_UDP

Attached Files
.zip

A16S_LAN8720_UDP.zip (Size: 1.1 KB / Downloads: 560)

[Arduino source code for KC868-A16S]-04 ADC_code

Posted by: KinCony Support - 04-14-2023, 02:46 AM - Forum: KC868-A16S - No Replies

Code:
#include "Arduino.h"

#define ANALOG_A1   36

#define ANALOG_A2   34

#define ANALOG_A3   35

#define ANALOG_A4   39

void setup()

{

    Serial.begin(115200);

    delay(1000);

  pinMode(ANALOG_A1,INPUT);

  pinMode(ANALOG_A2,INPUT);

  pinMode(ANALOG_A3,INPUT);

  pinMode(ANALOG_A4,INPUT);

}

void loop()

{

  if(digitalRead(ANALOG_A1)!=0){

    Serial.printf("A1 on Pin(%d)=%d\n",ANALOG_A1,analogRead(ANALOG_A1));

  }

  if(digitalRead(ANALOG_A2)!=0){

    Serial.printf("A2 on Pin(%d)=%d\n",ANALOG_A2,analogRead(ANALOG_A2));

  }

  if(digitalRead(ANALOG_A3)!=0){

    Serial.printf("A3 on Pin(%d)=%d\n",ANALOG_A3,analogRead(ANALOG_A3));

  }

  if(digitalRead(ANALOG_A4)!=0){

    Serial.printf("A4 on Pin(%d)=%d\n",ANALOG_A4,analogRead(ANALOG_A4));

  }

  delay(100);

}

[Arduino source code for KC868-A16S]-04 ADC_code

Attached Files
.zip

A16S_ADC.zip (Size: 580 bytes / Downloads: 545)

[Arduino source code for KC868-A16S]-03 433_DECODE

Posted by: KinCony Support - 04-14-2023, 02:46 AM - Forum: KC868-A16S - No Replies

Code:
#include <RCSwitch.h>

RCSwitch mySwitch = RCSwitch();

void setup() {

  Serial.begin(9600);

  mySwitch.enableReceive(digitalPinToInterrupt(16));

}

void loop() {

  if (mySwitch.available()) {

    Serial.print("Received ");

    Serial.print( mySwitch.getReceivedValue() );

    Serial.print(" / ");

    Serial.print( mySwitch.getReceivedBitlength() );

    Serial.print("bit ");

    Serial.print("Protocol: ");

    Serial.println( mySwitch.getReceivedProtocol() );

    mySwitch.resetAvailable();

  }

}

[Arduino source code for KC868-A16S]-03 433_DECODE

Attached Files
.zip

A16S_433-decode.zip (Size: 584 bytes / Downloads: 574)

[Arduino source code for KC868-A16S]-02 PCF8574-OUTPUT

Posted by: KinCony Support - 04-14-2023, 02:45 AM - Forum: KC868-A16S - Replies (3)

Code:
#include "Arduino.h"

#include "PCF8574.h"

// Set i2c address

PCF8574 pcf8574_1(0x24,4,5);

PCF8574 pcf8574_2(0x25,4,5);

void setup()

{

  Serial.begin(115200);

//  delay(1000);

  // Set pinMode to OUTPUT

  pcf8574_1.pinMode(P0, OUTPUT);

  pcf8574_1.pinMode(P1, OUTPUT);

  pcf8574_1.pinMode(P2, OUTPUT);

  pcf8574_1.pinMode(P3, OUTPUT);

  pcf8574_1.pinMode(P4, OUTPUT);

  pcf8574_1.pinMode(P5, OUTPUT);

  pcf8574_1.pinMode(P6, OUTPUT);

  pcf8574_1.pinMode(P7, OUTPUT);

  pcf8574_2.pinMode(P0, OUTPUT);

  pcf8574_2.pinMode(P1, OUTPUT);

  pcf8574_2.pinMode(P2, OUTPUT);

  pcf8574_2.pinMode(P3, OUTPUT);

  pcf8574_2.pinMode(P4, OUTPUT);

  pcf8574_2.pinMode(P5, OUTPUT);

  pcf8574_2.pinMode(P6, OUTPUT);

  pcf8574_2.pinMode(P7, OUTPUT);

  Serial.print("Init pcf8574_1...");

  if (pcf8574_1.begin()){

    Serial.println("PCF8574_1_OK");

  }else{

    Serial.println("PCF8574_1_KO");

  }

  Serial.print("Init pcf8574_2...");

  if (pcf8574_2.begin()){

    Serial.println("PCF8574_2_OK");

  }else{

    Serial.println("PCF8574_2_KO");

  }

}

void loop()

{

  for(int i=0;i<=7;i++)

  {

    pcf8574_1.digitalWrite(i, LOW);

    delay(500);

  }

  for(int j=0;j<=7;j++)

  {

    pcf8574_2.digitalWrite(j,LOW);

    delay(500);

  }

 for(int i=0;i<=7;i++)

  {

    pcf8574_1.digitalWrite(i, HIGH);

    delay(500);

  }

  for(int j=0;j<=7;j++)

  {

    pcf8574_2.digitalWrite(j,HIGH);

    delay(500);

  }

}

[Arduino source code for KC868-A16S]-02 PCF8574-OUTPUT

Attached Files
.zip

A16S_RELAY_OUT.zip (Size: 717 bytes / Downloads: 579)

[Arduino source code for KC868-A16S]-01 PCF8574-INPUT

Posted by: KinCony Support - 04-14-2023, 02:45 AM - Forum: KC868-A16S - No Replies

Code:
#include "Arduino.h"

#include "PCF8574.h"

// Set i2c address

PCF8574 pcf8574_1(0x24,4,5);

PCF8574 pcf8574_2(0x25,4,5);

PCF8574 pcf8574_IN1(0x22,4,5);

PCF8574 pcf8574_IN2(0x23,4,5);

void setup()

{

  Serial.begin(115200);

//  delay(1000);

  // Set pinMode to OUTPUT

  for(int i=0;i<=7;i++)

  {

    pcf8574_IN1.pinMode(i, INPUT);

  }

  for(int i=0;i<=7;i++)

  {

    pcf8574_IN2.pinMode(i, INPUT);

  }

  for(int i=0;i<=7;i++)

  {

    pcf8574_1.pinMode(i, OUTPUT);

  }

  for(int i=0;i<=7;i++)

  {

    pcf8574_2.pinMode(i,OUTPUT);

  }

    pcf8574_1.begin();

    pcf8574_2.begin();

    pcf8574_IN1.begin();

    pcf8574_IN2.begin();

  /*pcf8574_IN1.pinMode(P0, INPUT);

  pcf8574_IN1.pinMode(P1, INPUT);

  pcf8574_IN1.pinMode(P2, INPUT);

  pcf8574_IN1.pinMode(P3, INPUT);

  pcf8574_IN1.pinMode(P4, INPUT);

  pcf8574_IN1.pinMode(P5, INPUT);

  pcf8574_IN1.pinMode(P6, INPUT);

  pcf8574_IN1.pinMode(P7, INPUT);

  pcf8574_IN2.pinMode(P0, INPUT);

  pcf8574_IN2.pinMode(P1, INPUT);

  pcf8574_IN2.pinMode(P2, INPUT);

  pcf8574_IN2.pinMode(P3, INPUT);

  pcf8574_IN2.pinMode(P4, INPUT);

  pcf8574_IN2.pinMode(P5, INPUT);

  pcf8574_IN2.pinMode(P6, INPUT);

  pcf8574_IN2.pinMode(P7, INPUT);

pcf8574_IN1.begin();

pcf8574_IN2.begin();

  /*Serial.print("Init pcf8574_IN1...");

  if (pcf8574_IN1.begin()){

    Serial.println("pcf8574_IN1_OK");

  }else{

    Serial.println("pcf8574_IN1_KO");

  }

  Serial.print("Init pcf8574_IN2...");

  if (pcf8574_IN2.begin()){

    Serial.println("pcf8574_IN2_OK");

  }else{

    Serial.println("pcf8574_IN2_KO");

  }*/

}

void loop()

{

    for(int i=0;i<=7;i++)

    {

      if(pcf8574_IN1.digitalRead(i)==LOW)

      {

        Serial.printf("KEY  %d PRESSED\n",i+1);

        pcf8574_1.digitalWrite(i,LOW);

      }else pcf8574_1.digitalWrite(i,HIGH);

      delay(10);

    }

 for(int i=0;i<=7;i++)

    {

      if(pcf8574_IN2.digitalRead(i)==LOW)

      {

        Serial.printf("KEY %d PRESSED\n",i+9);

        pcf8574_2.digitalWrite(i,LOW);

      }else pcf8574_2.digitalWrite(i,HIGH);

      delay(10);

    }

}

[Arduino source code for KC868-A16S]-01 PCF8574-INPUT

Attached Files
.zip

A16S__INPUT.zip (Size: 824 bytes / Downloads: 581)

KC868-A8M configure yaml for ESPhome

Posted by: admin - 04-14-2023, 02:10 AM - Forum: KC868-A8M - Replies (11)

esphome:
name: a8m
platform: ESP32
board: esp32dev

remote_receiver:
pin: 16
dump:
- rc_switch
tolerance: 50%
filter: 250us
idle: 2ms
buffer_size: 2kb

# Example configuration entry for ESP32
i2c:
sda: 5
scl: 4
scan: true
id: bus_a

# Example configuration entry
ethernet:
type: LAN8720
mdc_pin: GPIO23
mdio_pin: GPIO18
clk_mode: GPIO17_OUT
phy_addr: 0

# Optional manual IP
manual_ip:
static_ip: 192.168.1.199
gateway: 192.168.1.1
subnet: 255.255.255.0

# Example configuration entry
pcf8574:
- id: 'pcf8574_hub_out_1' # for output channel 1-8
address: 0x24

- id: 'pcf8574_hub_in_1' # for input channel 1-8
address: 0x22

# Individual outputs
switch:
- platform: gpio
name: "light1"
id: light1
pin:
pcf8574: pcf8574_hub_out_1
number: 0
mode: OUTPUT
inverted: true

- platform: gpio
name: "light2"
id: light2
pin:
pcf8574: pcf8574_hub_out_1
number: 1
mode: OUTPUT
inverted: true

- platform: gpio
name: "light3"
id: light3
pin:
pcf8574: pcf8574_hub_out_1
number: 2
mode: OUTPUT
inverted: true

- platform: gpio
name: "light4"
id: light4
pin:
pcf8574: pcf8574_hub_out_1
number: 3
mode: OUTPUT
inverted: true

- platform: gpio
name: "curtain1-up"
id: relay5
pin:
pcf8574: pcf8574_hub_out_1
number: 4
mode: OUTPUT
inverted: true

- platform: gpio
name: "curtain1-down"
id: relay6
pin:
pcf8574: pcf8574_hub_out_1
number: 5
mode: OUTPUT
inverted: true

- platform: gpio
name: "curtain2-up"
id: relay7
pin:
pcf8574: pcf8574_hub_out_1
number: 6
mode: OUTPUT
inverted: true

- platform: gpio
name: "curtain2-down"
id: relay8
pin:
pcf8574: pcf8574_hub_out_1
number: 7
mode: OUTPUT
inverted: true

binary_sensor:
- platform: gpio
name: "input1"
on_press:
then:
- switch.toggle: light1
pin:
pcf8574: pcf8574_hub_in_1
number: 0
mode: INPUT
inverted: true

- platform: gpio
name: "input2"
on_press:
then:
- switch.toggle: light2
pin:
pcf8574: pcf8574_hub_in_1
number: 1
mode: INPUT
inverted: true

- platform: gpio
name: "input3"
on_press:
then:
- switch.toggle: light3
pin:
pcf8574: pcf8574_hub_in_1
number: 2
mode: INPUT
inverted: true

- platform: gpio
name: "input4"
on_press:
then:
- switch.toggle: light4
pin:
pcf8574: pcf8574_hub_in_1
number: 3
mode: INPUT
inverted: true

- platform: gpio
name: "input5"
on_press:
then:
- switch.toggle: relay5
pin:
pcf8574: pcf8574_hub_in_1
number: 4
mode: INPUT
inverted: true

- platform: gpio
name: "input6"
on_press:
then:
- switch.toggle: relay6
pin:
pcf8574: pcf8574_hub_in_1
number: 5
mode: INPUT
inverted: true

- platform: gpio
name: "input7"
on_press:
then:
- switch.toggle: relay7
pin:
pcf8574: pcf8574_hub_in_1
number: 6
mode: INPUT
inverted: true

- platform: gpio
name: "input8"
on_press:
then:
- switch.toggle: relay8
pin:
pcf8574: pcf8574_hub_in_1
number: 7
mode: INPUT
inverted: true

- platform: remote_receiver
name: "remoter1"
rc_switch_raw:
code: '000101000101010100000011'
protocol: 2
on_press:
then:
- switch.toggle: light1
filters:
- delayed_off: 200ms

- platform: remote_receiver
name: "remoter2"
rc_switch_raw:
code: '000101000101010100001100'
protocol: 2
on_press:
then:
- switch.toggle: light2
filters:
- delayed_off: 200ms

- platform: remote_receiver
name: "remoter3"
rc_switch_raw:
code: '001111010111001010110100'
protocol: 2
on_press:
then:
- switch.toggle: light3
filters:
- delayed_off: 200ms

- platform: remote_receiver
name: "remoter4"
rc_switch_raw:
code: '001111010111001010111001'
protocol: 2
on_press:
then:
- switch.toggle: light4
filters:
- delayed_off: 200ms

- platform: remote_receiver
name: "remoter5"
rc_switch_raw:
code: '001111010111001010110010'
protocol: 2
on_press:
then:
- switch.toggle: relay5
filters:
- delayed_off: 200ms

- platform: remote_receiver
name: "remoter6"
rc_switch_raw:
code: '001111010111001010110101'
protocol: 2
on_press:
then:
- switch.toggle: relay6
filters:
- delayed_off: 200ms

- platform: remote_receiver
name: "remoter7"
rc_switch_raw:
code: '001111010111001010110001'
protocol: 2
on_press:
then:
- switch.toggle: relay7
filters:
- delayed_off: 200ms

- platform: remote_receiver
name: "remoter8"
rc_switch_raw:
code: '001111010111001010110011'
protocol: 2
on_press:
then:
- switch.toggle: relay8
filters:
- delayed_off: 200ms

# Enable logging
logger:

# Enable Home Assistant API
api:

.txt KC868-A8M-ha-config.txt (Size: 5.68 KB / Downloads: 591)

KC868-A8M ESP32 I/O pin define

Posted by: admin - 04-14-2023, 02:09 AM - Forum: KC868-A8M - Replies (2)

#define ANALOG_A1 34
#define ANALOG_A2 35
#define ANALOG_A3 36
#define ANALOG_A4 39

IIC SDA:5
IIC SCL:4

Relay_IIC_address 0x24

Input_IIC_address 0x22

DS18B20/DHT11/DHT21/LED strip -2: 14

RF433MHz wireless receiver: 16

Ethernet (LAN8720) I/O define:

#define ETH_ADDR 0
#define ETH_POWER_PIN -1
#define ETH_MDC_PIN 23
#define ETH_MDIO_PIN 18
#define ETH_TYPE ETH_PHY_LAN8720
#define ETH_CLK_MODE ETH_CLOCK_GPIO17_OUT

GSM/RS485:
RXD:GPIO15
TXD:GPIO13

CAN bus:
TXD:GPIO32
RXD:GPIO33

KC868-A16S configure yaml for ESPhome

Posted by: admin - 04-14-2023, 02:08 AM - Forum: KC868-A16S - Replies (23)

esphome:
name: kc868-a16s
platform: ESP32
board: esp32dev

# Example configuration entry for ESP32
i2c:
sda: 4
scl: 5
scan: true
id: bus_a

# Example configuration entry
ethernet:
type: LAN8720
mdc_pin: GPIO23
mdio_pin: GPIO18
clk_mode: GPIO17_OUT
phy_addr: 0

# Optional manual IP
# manual_ip:
# static_ip: 192.168.1.199
# gateway: 192.168.1.1
# subnet: 255.255.255.0

# Example configuration entry
pcf8574:
- id: 'pcf8574_hub_out_1' # for output channel 1-8
address: 0x24

- id: 'pcf8574_hub_out_2' # for output channel 9-16
address: 0x25

- id: 'pcf8574_hub_in_1' # for input channel 1-8
address: 0x22

- id: 'pcf8574_hub_in_2' # for input channel 9-16
address: 0x23

# Individual outputs
switch:
- platform: gpio
name: "a16s-output1"
pin:
pcf8574: pcf8574_hub_out_1
number: 0
mode: OUTPUT
inverted: true

- platform: gpio
name: "a16s-output2"
pin:
pcf8574: pcf8574_hub_out_1
number: 1
mode: OUTPUT
inverted: true

- platform: gpio
name: "a16s-output3"
pin:
pcf8574: pcf8574_hub_out_1
number: 2
mode: OUTPUT
inverted: true

- platform: gpio
name: "a16s-output4"
pin:
pcf8574: pcf8574_hub_out_1
number: 3
mode: OUTPUT
inverted: true

- platform: gpio
name: "a16s-output5"
pin:
pcf8574: pcf8574_hub_out_1
number: 4
mode: OUTPUT
inverted: true

- platform: gpio
name: "a16s-output6"
pin:
pcf8574: pcf8574_hub_out_1
number: 5
mode: OUTPUT
inverted: true

- platform: gpio
name: "a16s-output7"
pin:
pcf8574: pcf8574_hub_out_1
number: 6
mode: OUTPUT
inverted: true

- platform: gpio
name: "a16s-output8"
pin:
pcf8574: pcf8574_hub_out_1
number: 7
mode: OUTPUT
inverted: true

- platform: gpio
name: "a16s-output9"
pin:
pcf8574: pcf8574_hub_out_2
number: 0
mode: OUTPUT
inverted: true

- platform: gpio
name: "a16s-output10"
pin:
pcf8574: pcf8574_hub_out_2
number: 1
mode: OUTPUT
inverted: true

- platform: gpio
name: "a16s-output11"
pin:
pcf8574: pcf8574_hub_out_2
number: 2
mode: OUTPUT
inverted: true

- platform: gpio
name: "a16s-output12"
pin:
pcf8574: pcf8574_hub_out_2
number: 3
mode: OUTPUT
inverted: true

- platform: gpio
name: "a16s-output13"
pin:
pcf8574: pcf8574_hub_out_2
number: 4
mode: OUTPUT
inverted: true

- platform: gpio
name: "a16s-output14"
pin:
pcf8574: pcf8574_hub_out_2
number: 5
mode: OUTPUT
inverted: true

- platform: gpio
name: "a16s-output15"
pin:
pcf8574: pcf8574_hub_out_2
number: 6
mode: OUTPUT
inverted: true

- platform: gpio
name: "a16s-output16"
pin:
pcf8574: pcf8574_hub_out_2
number: 7
mode: OUTPUT
inverted: true

binary_sensor:
- platform: gpio
name: "a16s-input1"
pin:
pcf8574: pcf8574_hub_in_1
number: 0
mode: INPUT
inverted: true

- platform: gpio
name: "a16s-input2"
pin:
pcf8574: pcf8574_hub_in_1
number: 1
mode: INPUT
inverted: true

- platform: gpio
name: "a16s-input3"
pin:
pcf8574: pcf8574_hub_in_1
number: 2
mode: INPUT
inverted: true

- platform: gpio
name: "a16s-input4"
pin:
pcf8574: pcf8574_hub_in_1
number: 3
mode: INPUT
inverted: true

- platform: gpio
name: "a16s-input5"
pin:
pcf8574: pcf8574_hub_in_1
number: 4
mode: INPUT
inverted: true

- platform: gpio
name: "a16s-input6"
pin:
pcf8574: pcf8574_hub_in_1
number: 5
mode: INPUT
inverted: true

- platform: gpio
name: "a16s-input7"
pin:
pcf8574: pcf8574_hub_in_1
number: 6
mode: INPUT
inverted: true

- platform: gpio
name: "a16s-input8"
pin:
pcf8574: pcf8574_hub_in_1
number: 7
mode: INPUT
inverted: true

- platform: gpio
name: "a16s-input9"
pin:
pcf8574: pcf8574_hub_in_2
number: 0
mode: INPUT
inverted: true

- platform: gpio
name: "a16s-input10"
pin:
pcf8574: pcf8574_hub_in_2
number: 1
mode: INPUT
inverted: true

- platform: gpio
name: "a16s-input11"
pin:
pcf8574: pcf8574_hub_in_2
number: 2
mode: INPUT
inverted: true

- platform: gpio
name: "a16s-input12"
pin:
pcf8574: pcf8574_hub_in_2
number: 3
mode: INPUT
inverted: true

- platform: gpio
name: "a16s-input13"
pin:
pcf8574: pcf8574_hub_in_2
number: 4
mode: INPUT
inverted: true

- platform: gpio
name: "a16s-input14"
pin:
pcf8574: pcf8574_hub_in_2
number: 5
mode: INPUT
inverted: true

- platform: gpio
name: "a16s-input15"
pin:
pcf8574: pcf8574_hub_in_2
number: 6
mode: INPUT
inverted: true

- platform: gpio
name: "a16s-input16"
pin:
pcf8574: pcf8574_hub_in_2
number: 7
mode: INPUT
inverted: true

# Enable logging
logger:

# Enable Home Assistant API
api:

.txt Made_for_ESPHome_KC868-A16S.txt (Size: 5.63 KB / Downloads: 845)

KC868-A16S ESP32 I/O pin define

Posted by: admin - 04-14-2023, 02:07 AM - Forum: KC868-A16S - Replies (2)

ANALOG_A1 GPIO36
ANALOG_A2 GPIO34
ANALOG_A3 GPIO35
ANALOG_A4 GPIO39

IIC SDA:GPIO4
IIC SCL:GPIO5

1-wire GPIO: GPIO14

PCF8574:U27 (relay1-8): 100 100 = 0x24
PCF8574:U28 (relay9-16): 100 101 = 0x25

PCF8574:U23 (DI1-8): 100 010 = 0x22
PCF8574:U24 (DI9-16): 100 011 = 0x23

RF433MHz wireless receiver: GPIO16

Ethernet (LAN8720) I/O define:

#define ETH_ADDR 0
#define ETH_POWER_PIN -1
#define ETH_MDC_PIN 23
#define ETH_MDIO_PIN 18
#define ETH_TYPE ETH_PHY_LAN8720
#define ETH_CLK_MODE ETH_CLOCK_GPIO17_OUT

--------------------
RS485:
RXD:GPIO32
TXD:GPIO33

GSM:
RXD:GPIO15
TXD:GPIO13

kc868-a2 SIM7600

Posted by: petez69 - 04-13-2023, 08:26 AM - Forum: KC868-A series and Uair Smart Controller - Replies (6)

	Hi Kincony I am using Homeassistant and ESPHome. I am looking to use kc868-a2 and SIM7600SA(Australia) with ESPHOme. I see there is a SIM800L library for 2G boards. Do you know if SIM7600 will work with SIM800L ESPhome configuration ? Thankyou..Peter

Pages (378): « Previous 1 … 256 257 258 259 260 261 262 263 264 265 266 267 268 269 270 271 272 273 274 275 276 … 378 Next »

Login
Username:
Password:	Lost Password?
	Remember me
