v3.9.0 improvement:

1. fixed wifi can't disable in "AP" mode.
2. add support new controller F8 & A2v3 & A8v3 & B8M & TA

Attached Files

  KCS_A2V3_V3.9.0.zip (Size: 1.03 MB / Downloads: 743)
  KCS_A6V3_V3.9.0.zip (Size: 1.01 MB / Downloads: 832)
  KCS_A8V3_V3.9.0.zip (Size: 1.06 MB / Downloads: 782)
  KCS_A16V3_V3.9.0.zip (Size: 1.08 MB / Downloads: 759)
  KCS_A32PRO_V3.9.0.zip (Size: 1.05 MB / Downloads: 825)
  KCS_AG8_V3.9.0.zip (Size: 1.04 MB / Downloads: 765)
  KCS_B8M_V3.9.0.zip (Size: 1.07 MB / Downloads: 797)
  KCS_B16_V3.9.0.zip (Size: 1.07 MB / Downloads: 793)
  KCS_B16M_V3.9.0.zip (Size: 1.07 MB / Downloads: 752)
  KCS_F8_V3.9.0.zip (Size: 1.06 MB / Downloads: 750)
  KCS_F16_V3.9.0.zip (Size: 1.08 MB / Downloads: 733)
  KCS_F24_V3.9.0.zip (Size: 1.08 MB / Downloads: 803)
  KCS_G1_V3.9.0.zip (Size: 1.03 MB / Downloads: 742)
  KCS_KC_TA_V3.9.0.zip (Size: 1.03 MB / Downloads: 760)
  KCS_T16M_V3.9.0.zip (Size: 1.02 MB / Downloads: 766)

KinCony TA (Tiny Alarm System) ESP32-S3 smart controller based on ESP32-S3-WROOM-1U (N16R8) wifi chip and Tuya module. It have 12 channel digital input (12-zone) and 2 channel relay output for sirens or strobe lights, 12 channel 1-wire GPIOs, DS3231 high precision RTC clock chip.TA added Power over Ethernet (PoE). TA have RS485 port and RF433MHz RF receiver. You can write any code by Arduino IDE / MicroPython / ESP-IDF development tool to ESP32 module. We will supply Arduino demo code for different samples. Everyone can modify and change the code for your own smart home automation system project. it support use by ESPHome for home assistant or tasmota firmware for smart home automation DIY. TA use KCS v3 firmware, it support home assistant auto discovery function by MQTT, so without write any config code (zero code) for home assistant. KCS v3 support Apple HomeKit. Tuya mobile phone APP remote monitor 12 channel digital input port state, 12 channel temperature sensors and control 2 channel relay by internet.

Model No. KinCony TA


Description: KinCony ESP32-S3 Tiny Alarm System – TA
Power supply: 12V DC
Processor: ESP32-S3-WROOM-1U (N16R8)
Size: 115mm*83mm*45mm
interfaces: Ethernet(RJ45)-LAN 100Mbps IPv4/IPv6 POE,WiFi,RS485,Bluetooth,USB-C,Tuya Module
RTC: DS3231 high precision chip (battery socket on PCB)
Installation method: DIN RAIL

I am using a kincony A16v3 board for my project. I have tried to upload my arduino code to the board. But the code is not uploading. I have powered the board with 12v supply. And have connected the board to my pc via usb type c cable.

Chosen nodemcu 32s in boards. But its not working. How to check what have gone wrong ?. Or if any further details required, let me know

Hi guys,

I have PIR sensors all over the house connected to an old alarm system. The voltage on the NO contacts are between 1.5v to 3v, which I think is too low for the digital inputs 1 to 16 to register as ON.
I know I can connect to the 5 analog inputs, which does detect the low voltage, but I have ~15 sensors. Is there a way to make these low voltage PIR sensors detectable on digital inputs 1 to 16? Without using a ton of dry contact relays haha

Thank you in advance!

Hello,

I tried changing the MODBUS address from MODBUS ID 1 to 15 on the RS-485 SHT30 temperature and relative humidity module through a function 6 write, disconnected the connector for 5 to 10 seconds, reconnected the connector, and polled the sensor over MODBUS. However, the device only responds to MODBUS ID 1, but I can see the updated MODBUS address in register 0x0a as 0x0F.

Is there another setting that has to be configured?

Hello!

I recently purchased a KC868-a16 and Im in the process of exploring the KCS server. Yesterday I successfully downloaded the firmware onto the board and was able to scan the ethernet network of the board. I used the eth IP to sign into the website but when I switch the networks setting from AP to STA, there was no STA Wifi IP address after refresh. Can you please advise me on what I may be doing wrong.

Thank you!

Attached Files

Thumbnail(s)

Image(s)


Hi,

i have succefully integrate board A16V3 via MQTT auto discovery to Homeassistant. But i didnt found how can i add now KC868-HAv2. If i create new device in ESPHome and copy data from github:
https://github.com/hzkincony/esphome-kc868-ha

I cant install it, ESP gives me error:


Failed config
'esphome' section missing from configuration. Please make sure your configuration has an 'esphome:' line in it.

Do i also need to add main board A16V3 to ESP home and just add those lines to config file of A16V3, or can KC868-HAv2 be add as standalone?

Hi

I need to use other CT with different CT ratio.
In ESPHome I can Change IT.
But need IT in the Webpage (stand alone use).
IS IT planed to integrate IT in the UI?
Or IS the source Code available?

BR
Linus

Looking to use an MB board (KinCony ESP32 Battery Monitor) to monitor DC circuit power.

I can't tell from the specification if it's 8A per channel or 8A for all 16 channels?

And it's unclear if it can be different voltage on every channel? Can I have 12VDC on one channel and 24VDC on another channel and have correct measurements on both?

thank you.
-Greg

I am trying to use one of the outputs to drive a 12v siren directly.  I have a 12v power supply, with 12v passing from the input to the 12v terminal on the output block.  If I connect my siren to the 12v and output terminal on the block, it doesn't sound properly, and if I measure the voltage across them with a multimeter I am only seeing ~10.5v.
Is this a limitation of the board, or have I wired something wrong?
