KC868-A2v3 ESPHome yaml for home assistant

Posted by: admin - 04-20-2025, 05:46 AM - Forum: KC868-A2v3 - Replies (2)

Code:
esphome:

  name: a2v3

  friendly_name: a2v3

esp32:

  board: esp32-s3-devkitc-1

  framework:

    type: arduino

# Enable logging

logger:

# Enable Home Assistant API

api:

ethernet:

  type: W5500

  clk_pin: GPIO42

  mosi_pin: GPIO43

  miso_pin: GPIO44

  cs_pin: GPIO41

  interrupt_pin: GPIO2

  reset_pin: GPIO1

i2c:

   - id: bus_a

     sda: 48

     scl: 47

     scan: true

     frequency: 400kHz

uart:

  - id: uart_1

    baud_rate: 9600

    debug:

      direction: BOTH

      dummy_receiver: true

      after:

        timeout: 10ms

    tx_pin: 7

    rx_pin: 15

  - id: uart_sim7600

    baud_rate: 115200

    debug:

      direction: BOTH

      dummy_receiver: true

      after:

        timeout: 10ms

      sequence:

        - lambda: UARTDebug::log_string(direction, bytes);

    tx_pin: 10

    rx_pin: 9

switch:

  - platform: gpio

    pin: 40

    name: "A2v3-Relay1"

  - platform: gpio

    pin: 39

    name: "A2v3-Relay2"

  - platform: uart

    uart_id: uart_1

    name: "RS485 Button"

    data: [0x11, 0x22, 0x33, 0x44, 0x55]

  - platform: uart

    uart_id: uart_sim7600

    name: "UART 4G"

    data: "AT+CGSN\r\n" # read 4G SIM7600 ID

binary_sensor:

  - platform: gpio

    name: "A2v3-input1"

    pin:

      number: 16

      inverted: true

  - platform: gpio

    name: "A2v3-input2"

    pin:

      number: 17

      inverted: true

  - platform: gpio

    name: "IO18"

    pin:

      number: 18

      inverted: true

  - platform: gpio

    name: "IO8"

    pin:

      number: 8

      inverted: true

  - platform: gpio

    name: "IO4"

    pin:

      number: 4

      mode:

        input: true

        pullup: true

      inverted: true

  - platform: gpio

    name: "IO5"

    pin:

      number: 5

      mode:

        input: true

        pullup: true

      inverted: true

  - platform: gpio

    name: "IO6"

    pin:

      number: 6

      mode:

        input: true

        pullup: true

      inverted: true

  - platform: gpio

    name: "IO38"

    pin:

      number: 38

      mode:

        input: true

        pullup: true

      inverted: true

web_server:

  port: 80

font:

  - file: "gfonts://Roboto"

    id: roboto

    size: 20

display:

  - platform: ssd1306_i2c

    i2c_id: bus_a

    model: "SSD1306 128x64"

    address: 0x3C

    lambda: |-

      it.printf(0, 0, id(roboto), "A2v3");

esphome yaml file download:

.txt

A2v3-HA.txt (Size: 2.39 KB / Downloads: 564)

KC868-A2v3 ESP32-S3 IO pins define

Posted by: admin - 04-20-2025, 05:44 AM - Forum: KC868-A2v3 - No Replies

IIC Bus:

SDA:GPIO48
SCL:GPIO47

24C02 EPROM i2c address: 0x50
DS3231 RTC i2c address: 0x68
SSD1306 display: i2c address:0x3c
-----------------

1-wire (pull-up resistance on PCB):
1-wire(TMP1):GPIO18
1-wire(TMP2):GPIO8

free GPIOs (without pull-up resistance on PCB):
free gpio-1:GPIO4
free gpio-2:GPIO5
free gpio-3:GPIO6
free gpio-4:GPIO38
-----------------

Ethernet (W5500) I/O define:

clk_pin: GPIO42
mosi_pin: GPIO43
miso_pin: GPIO44
cs_pin: GPIO41

interrupt_pin: GPIO2
reset_pin: GPIO1

--------------------
RS485:
RXD:GPIO15
TXD:GPIO7

4G module:
RXD:GPIO9
TXD:GPIO10

--------------------
SD Card:
SPI-MOSI:GPIO12
SPI-SCK:GPIO13
SPI-MISO:GPIO14
SPI-CS:GPIO11
SPI-CD:GPIO21

--------------------
Relay1:GPIO40
Relay2:GPIO39

--------------------
digital input-1:GPIO16
digital input-2:GPIO17

KC868-A16 IR Input

Posted by: cyberrailpete - 04-20-2025, 05:33 AM - Forum: KC868-A16 - Replies (11)

	Hello. I have a KC868-A16 - Great board. I have a number of IR sensors that need to send back state via MQTT to different topics so have had to write custom sketch in Aurdino IDE. Problem is the sensor never goes inactive. I have tested the IR with a meter and voltage drop on digital out when active and high when inactive. KC868-A16 seems to be 12v on the input which is weird. Help please!

RF Transmitter not working in ESPHome

Posted by: johnsmith8439 - 04-19-2025, 04:20 PM - Forum: KC868-AG / AG Pro / AG8 / Z1 - Replies (4)

Hello,
I installed ESPHome on the KC868-AG. RF receiver works, I can receive RF signals from the smart plug's remote:

[23:17:05][I][remote.rc_switch:261]: Received RCSwitch Raw: protocol=2 data='10010010001010100110110110010011'
[23:17:05][I][remote.rc_switch:261]: Received RCSwitch Raw: protocol=2 data='10010010001010100110110110010011'
[23:17:05][I][remote.rc_switch:261]: Received RCSwitch Raw: protocol=2 data='10010010001010100110110110010011'
[23:17:05][I][remote.rc_switch:261]: Received RCSwitch Raw: protocol=2 data='1001001000101010011011011001001'

But transmitter doesn't work, I cannot control the smart plug with RF using the transmitter.

The log after using transmitter:
[23:29:02][D][button:010]: 'Smart Plug On' Pressed.
[23:29:02][W][component:239]: Component api took a long time for an operation (287 ms).
[23:29:02][W][component:240]: Components should block for at most 30 ms.
[23:29:02][I][remote.rc_switch:261]: Received RCSwitch Raw: protocol=2 data='10010010001010100110110110010011'
[23:29:02][I][remote.rc_switch:261]: Received RCSwitch Raw: protocol=2 data='10010010001010100110110110010011'
[23:29:02][I][remote.rc_switch:261]: Received RCSwitch Raw: protocol=2 data='10010010001010100110110110010011'
[23:29:02][I][remote.rc_switch:261]: Received RCSwitch Raw: protocol=2 data='1001001000101010011011011001001'

Here is my ESPHome code:

Code:
remote_transmitter:

  - id: transmitter_ir

    pin: GPIO2

    carrier_duty_percent: 50%

  - id: transmitter_rf

    pin: GPIO22

    carrier_duty_percent: 50%

remote_receiver:

  # see https://esphome.io/components/remote_transmitter.html#setting-up-infrared-devices

  # for details on discovering the correct codes for your devices

  - id: receiver_ir

    pin:

      number: GPIO23

      inverted: True

    dump: rc_switch

  # see https://esphome.io/components/remote_transmitter.html#setting-up-rf-devices

  # for details on discovering the correct codes for your devices

  - id: receiver_rf

    pin:

      number: GPIO13

    dump: rc_switch

    # Settings to optimize recognition of RF devices

    tolerance: 50%

    filter: 250us

    idle: 4ms

    buffer_size: 2kb

button:

  - platform: template

    name: "Door Chime"

    on_press:

      - remote_transmitter.transmit_rc_switch_raw:

          transmitter_id: transmitter_rf

          protocol: 5

          code: "001010100010100000"

          repeat:

            times: 10

            wait_time: 0s

  - platform: template

    name: "Smart Plug On"

    on_press:

      - remote_transmitter.transmit_rc_switch_raw:

          transmitter_id: transmitter_rf

          protocol: 2

          code: "10010010001010100110110110010011"

          repeat:

            times: 10

            wait_time: 0s

  - platform: template

    name: "Smart Plug Off"

    on_press:

      - remote_transmitter.transmit_rc_switch_raw:

          transmitter_id: transmitter_rf

          protocol: 2

          code: "01000100101011010110100011010011"

          repeat:

            times: 10

            wait_time: 0s

Input protection

Posted by: wchpikus - 04-19-2025, 02:51 PM - Forum: Development - Replies (5)

	Hello One of binary input stop working.. I checked and translator was damage. I do not know-how how, but it could be protect emc or overload. I just replace them, but I wojny about induction when I will connect them to 20m ftp.

Kc-868-a32 uart

Posted by: wchpikus - 04-18-2025, 06:51 PM - Forum: KC868-A32/A32 Pro - Replies (3)

	Hello What ping are used to rs485? Failed config uart: [source /config/esphome/rolety-kc868-a32.yaml:27] - id: uart_modbus baud_rate: 9600 tx_pin: 9 This pin cannot be used on ESP32s and is already used by the flash interface (function: Flash Data 1). rx_pin: 8 Regards

Soil moisture sensors

Posted by: xarouli5 - 04-18-2025, 06:03 PM - Forum: KC868-AIO - Replies (10)

	I bought the next sensor to experiment: Soil Moisture Sensor https://a.aliexpress.com/_ExqUPDK Powered 3.3v, gnd and tried AO on AI (9-16) & DO on DI (1-8). No change seen on inputs of AIO when I dipped sensor in water and out. Any ideas?

24V Support

Posted by: yawniek - 04-18-2025, 05:06 PM - Forum: Suggestions and feedback on KinCony's products - Replies (2)

	Hi, It would be good to be able to see more prominently which products support 24V input voltage and which products do not support it. Sometimes the board notes 12V but they work with 24V and sometimes not. Could you clarify which products support 24V and maybe put input voltage more clearly into descriptions? Thank You Y

[arduino code examples for A6v3]-12 Read DS18B20 by 1-wire

Posted by: admin - 04-18-2025, 05:33 AM - Forum: KC868-A6v3 - No Replies

	here is ESP32 DS18B20 arduino library for KC868-A6v3. esp32-ds18b20-main.zip (Size: 6.49 KB / Downloads: 813)

KC868-AP JSON not valid

Posted by: simpl3x - 04-17-2025, 11:49 AM - Forum: KC868-AP / ADR - Replies (5)

Have KC868-AP

Code:
Board Model

KC868_AP

Software Version

v2.2.12

Build Date

Feb 28 2025 14:41:30

Serial Number

C82E18C85DFC

I try integrate it to Home Assistant over MQTT, but it not working.
I have this template:

Code:
mqtt:

  light:

  - name: 'KC868-AP-1-DIMM-1'

    unique_id: KC868-AP-1-DIMM-1

    schema: template

    command_topic: "KC868_AP/C82E18C85DFC/SET"

    state_topic: "KC868_AP/C82E18C85DFC/STATE"

    command_on_template: >

      {% if brightness is defined %}

      {"dac1":{"value":{{(brightness / 255  * 100) | int - 1}}}

      {% else %}

      {"dac1":{"value":255}}

      {% endif %}

    command_off_template: >

      {"dac1":{"value":0}}

    state_template: >

      {% if value_json.dac1.value == 0 %}

      off

      {% else %}

      on

      {% endif %}

    brightness_template: >

      {{ (value_json.dac1.value / 99 * 255) | int }}

when I change dimmer value in HA, message received on device and dimmer value is changed, but light state in HA still Unknown.
I try to check status JSON in linter and it have mistake:

Code:
{"input1":{"value":false},"input2":{"value":false},"input3":{"value":false},"input4":{"value":false},"input5":{"value":false},"input6":{"value":false},"input7":{"value":false},"input8":{"value":false},"input9":{"value":false},"input10":{"value":false},"input11":{"value":false},"input12":{"value":false},"input13":{"value":false},"input14":{"value":false},"input15":{"value":false},"input16":{"value":false},"input17":{"value":false},"input18":{"value":false},"output1":{"value":false},"output2":{"value":true},"dac1":{"value":0},"dac2":{"value":0},"dac3":{"value":0},"dac4":{"value":0},"dac5":{"value":0},"dac6":{"value":0},"dac7":{"value":0},"dac8":{"value":0},"dac9":{"value":0},"dac10":{"value":0},"dac11":{"value":0},"dac12":{"value":0},"dac13":{"value":0},"dac14":{"value":0},"dac15":{"value":0},"dac16":{"value":0},}

after "dac16":{"value":0}, has extra comma.
if I publish valid JSON in status topic without extra comma HA gets status of dimmer channel correct:

Code:
{"input1":{"value":false},"input2":{"value":false},"input3":{"value":false},"input4":{"value":false},"input5":{"value":false},"input6":{"value":false},"input7":{"value":false},"input8":{"value":false},"input9":{"value":false},"input10":{"value":false},"input11":{"value":false},"input12":{"value":false},"input13":{"value":false},"input14":{"value":false},"input15":{"value":false},"input16":{"value":false},"input17":{"value":false},"input18":{"value":false},"output1":{"value":false},"output2":{"value":true},"dac1":{"value":0},"dac2":{"value":0},"dac3":{"value":0},"dac4":{"value":0},"dac5":{"value":0},"dac6":{"value":0},"dac7":{"value":0},"dac8":{"value":0},"dac9":{"value":0},"dac10":{"value":0},"dac11":{"value":0},"dac12":{"value":0},"dac13":{"value":0},"dac14":{"value":0},"dac15":{"value":0},"dac16":{"value":0}}

Pages (423): « Previous 1 … 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 … 423 Next »
