I have problems. It doesn't connect.

Hello, I discover this item recently.
Before order one, I wish to now if it is possibile to connect an industrial sensor (Temperature and Humidity) that works in this way:

2-wires NTC 10K for the temperature
2-wires 4-20ma for the humidity

I need that the board sends values to a MQTT broker with ethernet.

any help?

Thank you very much

Hello,


After a modification via the web page of a parameter, the system says reboot in 5 seconds.

except that the system will never reboot, you always have to cut and reconnect the power supply.

It's exactly the same thing with the reset button..
Just ping the port and you can see that the card is not rebooted.

This is not normal.

I also noticed that after loading a firmware, the visible parameters (Example Modbus slave 1) are wrong.
Indeed it displays 1 but in fact it probably has another value because for it to be recognized as slave one you have to re-enter the value and save it, and then it works.


I test this product, I realize that it has no problems (see my posts) this is only on this card model or dear colleague have you seen this also on other card references?

I have the impression that the product is debugged by customers as bugs are found.

Hello,

In exchange for hardware (433M Receiver, SIM7600 4G, sensors), I would happily develop and/or validate components under the ESP-IDF environment with examples.

ESP-IDF components available at the moment: ESP-IDF Components (ESP32-S3)

KinCony S3 Core Development Board ESP-IDF demo application: RTU, I2C, 1-wire Demo Application

The development environment is under Visual Studio Code with the PlatformIO and ESP-IDF (>=v5.3.1) extensions.

Hello,

This demo application utilizes RS-485, 1-Wire, and I2C under the ESP-IDF environment.

KinCony S3 Core Development Board RTU, I2C, 1-wire Demo Application
The demo application interfaces the following sensors:

The demo application interfaces the following sensors:

• MODBUS RTU - RS2E radar precipitation sensor with temperature and humidity sensor

• MODBUS RTU - WDC2E ultrasonic anemometer

• I2C - BMP280 atmospheric pressure sensor

• 1-Wire - DS18B20 ground temperature sensor


I have Problems with Tasmota and the DS18x20 Temp sensor.....what is the config for the sensor ...in Tasmota ? I can not find the right configuration ? Need help please...

can you help me please....I conected the DS18x20 in correct way to the 868-A6 board. What do I need to change in TASMOTA to see the temperature ??? right now there is nothing to see...not over MQTT , not on the config Page of Tasmota board. (Server) I need help please !

I'm trying to use the outputs of the A16 to control the relays of a 16-Channel 12V Relay Module that will be used for AC lights. The board is is a low-level trigger and you can see in the following pictures that I'm testing relays 16 and 15 by wiring them to GND:





Both relays seems to work fine that way, but when I try to use the A16 outputs to control it here's what happens:
Notice that the relay 16 is triggered properly, but the LED on output 16 is lit with a dim light (I've set output 14 as ON so you can compare both LEDs)



Now if I try to use relay 15 it doesn't work:



Am I doing something wrong here? The A16 output LED getting a dim light when I connect it to the relay board seems a bit odd to me, and it not being able to control all relays on the module is also odd.

I've tested all relays connecting them directly to GND and they all work, but when I do it via the A16 outputs only some of them work (e.g. 16 and 14 works but 15 and 13 do not). Could this be an issue on the relay module?

The power supply that I'm using is a brand new Mean Well HDR-60-12

Dear all, I am using the K868-A4 board with KCS V2.2.10, I have a 4-20mA sensor connected to AI1 and I am receiving the values correctly on the Monitor.


https://authomathikacombr-my.sharepoint....A?e=v47SsH

My MQTT server is configured and turned on, I receive information from my digital inputs and outputs, when they change their state, but I need to receive the data from my AD1 input, I went to System and activated the "auto send ADC values" option which would have to send me the data every 5 seconds!
This does not happen!




https://authomathikacombr-my.sharepoint....A?e=nnugET

What should I do to make this configuration work?

Dear Support Team,

I hope this message finds you well. I have a few questions, and I would greatly appreciate your guidance and expertise:

1. How can I control four air conditioning units (Gree, Daikin, Samsung, and Toshiba) using four GPIO pins? Could you kindly assist me in setting up the ESPHome YAML file for this configuration?

2. Is it possible to utilize eight channels for controlling devices? If so, I would be grateful if you could provide some insights on how this can be implemented effectively.

3. Lastly, could you please share any updates on when the KCSFirmware will be released? I am eagerly looking forward to its availability.
