Product Parameters:



Operating voltage: 12v/DC

Operating temperature: 0 ℃ ~ 50 ℃

Output form: Relay N/C, N/O optional

Static power consumption: < 0.3w

Alarm power consumption: ≤ 0.5w

Operating humidity: 20%~100%RH

False positive rate: < 100ppm

Configuration: Standard 35lm probe cable



Terminals Description
  Red Working power 12v/DC positive pole
  Black Working power 12v/DC negative pole
  Yellow N/O or N/C with J1 set output form, N/O as default ,no polarity difference
  Green No water, the two terminals resistance infinitely large, no polarity difference
